9 . B Audio Outputs—
cables to these jacks if you want separate stereo outputs for Layer B. If
no cables are connected, Layer B is output on the Main A Outputs.
10 . Main/A Audio Outputs—
are the main stereo outputs for the synth. They carry Layer A and also
Layer B if no cables are connected to the "B Audio Outputs" jacks.
11 . Headphones—
is controlled by the

Using USB

The Prophet X's USB 2.0 port enables bidirectional MIDI communica-
tion with a computer. A MIDI interface and MIDI cables are not neces-
sary, just a USB cable. The Prophet X is a Class Compliant USB device.
That means it does not require any additional drivers to be installed to
communicate with a Mac or Windows computer. The Prophet X trans-
mits and receives MIDI data via USB, but does not transmit audio.
MIDI In and USB should not be used at the same time, as overlapping
messages from different sources may cause the Prophet X to respond unpredictably.
MIDI Out and USB can be used at the same time and transmit the same data.
Under Mac OS, "Prophet X" will appear as a MIDI port when connected
via USB and can be configured using the Mac's Audio MIDI Setup utility
(typically found in Applications/Utilities).
Under Windows, the first time the Prophet X is connected via USB, the
"Found new hardware" alert appears and it is automatically installed as
"Prophet X."
In Windows, if you unplug the USB cable and plug it back in while a
program has the Prophet X port open, you may have to resync. That
usually means going to the Prophet X Keyboard Properties — in the
Windows Device Manager under "Sound, video, and game control-
lers" — and clicking OK. If Prophet X is no longer listed in the Device
Manager, power the Prophet X down and back up again while it is
connected via USB. It should be detected on power up.
Using USB
116
Unbalanced, ¼ inch audio outputs. Connect audio
Unbalanced, ¼ inch audio outputs. These
An ¼ inch stereo headphone jack. Headphone volume
knob on the front panel.
volume
