1. INTRODUCTION ................................................. 2
1.1 System Features .......................................... 3
EXP-33 Expander Module .................................. 8
LE Expander Module .......................................... 9
Panel and Bracket Mounting ........................... 10
3.6 PGM-5 Installation ...................................... 13
3.7 PowerLink3 Installation ............................. 14
3.9.1 Battery Insertion ................................. 19
Panel ................................................................. 20
4.
........................................................................... 21
4.3 Using Proximity Tags................................. 22
5. MAINTENANCE ................................................ 22
5.2 Replacing the Backup Battery................... 22
5.3 Fuse Replacement ..................................... 22
5.5 Annual System Check................................ 22
APPENDIX A. Specifications............................... 23
A1. Functional .................................................. 23
A2. Wireless ...................................................... 23
A3. Electrical .................................................... 24
A4. Communication ......................................... 25
A5. Physical Properties ................................... 25
D-306917
PowerMaster-33 G2 Installer's Guide
PowerMaster-33 G2
Version 19.3
Installer's Guide

Table of Contents

Quick User Guide to Main Alarm Control
Operations by KP-250 PG2 Keypad .................... 31
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerMaster-33 G2 and is the answer not in the manual?

Questions and answers

Related Manuals for Visonic PowerMaster-33 G2

Summary of Contents for Visonic PowerMaster-33 G2

  • Page 1: Table Of Contents

    2. CHOOSING THE INSTALLATION LOCATION .. 7 Quick User Guide to Main Alarm Control Operations by KP-250 PG2 Keypad ....31 3. POWERMASTER-33 G2 INSTALLATION ..8 3.1.1 PowerMaster-33 G2 Wiring Diagram with EXP-33 Expander Module ........8 3.1.2 PowerMaster-33 G2 Wiring Diagram with LE Expander Module ..........

  • Page 2: Introduction

    It is a user friendly solution for both monitoring service providers and professional installers. The system consists of the PowerMaster-33 G2 control panel that operates in conjunction with a wireless keypad display device (KP-250 PG2). The control panel accommodates all control circuitry and operation software for a programmable 64-zone alarm system, while the keypad display unit enables the installer and the user to enter their commands, and provides visual and audible feedback.

  • Page 3: System Features

    Guide, Chapter 8 Periodic Test by User technical person at the location). Code To conduct a walk test from remote location: refer to the Remote Programmer PC software User's Guide, Chapter 6 Data Details Tables. D-306917 PowerMaster-33 G2 Installer's Guide...
  • Page 4 Installation Location. PowerG devices include a built-in link quality indicator. Choosing the mounting location is a quick and easy process. Supported in specific PowerMaster-33 G2 variants (for further details, please contact your Visonic representative). D-306917 PowerMaster-33 G2 Installer's Guide...
  • Page 5 Installer’s Guide, section 3.3 Setting Installer Codes Arming key External system can control arming and Connect the external system output to the disarming of the PowerMaster-33 system panel: see section 3.8 Optional Expander Module Mounting, Figure 3.8b D-306917 PowerMaster-33 G2 Installer's Guide...
  • Page 6 Smoke & Heat Temperature Smoke Detector KP-160 PG2 Detector Detector Sirens KP-250 PG2 FLD-550 PG2 GSD-441 PG2 GSD-442 PG2 Gas (Methane) Flood Carbon Monoxide (CO) SR-730 PG2 SR-720 PG2 Detector Detector Detector Outdoor Indoor Siren Siren D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 7: Choosing The Installation Location

    It is suggested to use the DSL alarm filter model Z-A431PJ31X manufactured by Excelsus Technologies, or equivalent. This filter simply plugs into the RJ-31X jack and allows alarm reporting without breaking the internet connection. D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 8: Powermaster-33 G2 Installation

    3. POWERMASTER-33 G2 INSTALLATION Required tool: Philips screwdriver #2. PowerMaster-33 G2 mounting process is shown in Figures 3.1 - 3.10. 3.1.1 PowerMaster-33 G2 Wiring Diagram with EXP-33 Expander Module A. Expander Module Flat B. Wired Zone / Special C. Battery Connector D.

  • Page 9: Powermaster-33 G2 Wiring Diagram With Le Expander Module

    L. Phone Wiring Connectors M. Cellular Module or External Power Supply Unit ** or External Power Connector *** or Terminal Block in North American Panels Figure 3.1.2 – PowerMaster-33 G2 Wiring Diagram with LE Expander and PGM-5 modules D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 10: Opening The Powermaster-33 G2 Control Panel And Bracket Mounting

    3.2 Opening the PowerMaster-33 G2 Control Panel and Bracket Mounting A. Mounting surface To Mount the Unit: 1. Release the screws B. Back panel 2. Remove the front cover C. 5 screws 3. Mark 5 drilling points on the mounting surface...

  • Page 11: Connecting Wired Zone And Siren

    G. Alarm N.C. Figure 3.4 – Wired Zone and Siren Wiring Wired zones can be enrolled in any zone in the PowerMaster-33 G2 control panel from 01 to 64 D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 12: Cellular Module And Sim Installation

    IMPORTANT! Do not insert or remove SIM card when system is powered by AC power or backup battery. the control panel is powered by AC power or battery. Figure 3.5 – Optional Cellular Module Mounting and SIM Card Insertion D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 13: Pgm-5 Installation

    Review Figure 3.1.2, symbol F identifies the location for the PGM-5 module. For more information about installing the PGM-5 module, see D-302182 PGM-5 Installation Instructions. PGM-5 module can be used in the panel only when the EXP-33 Expander Module or PowerLink3 Module is not in use. D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 14: Powerlink3 Installation

    A. Cat-5 cable to home router B. Flat cable B1. This side for front panel B2. This side for PowerLink3 Figure 3.6 – PowerLink3 Mounting D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 15: Exp-33 Expander Module Installation

    1. Press downward on the Expander module between the two clips to insert the module into the back panel. See Figure 3.7a EXP-33 Expander Module (A) to identify the clips. 2. Connect the EXP-33 Expander Module by the flat cable to the front panel Expander slot "EXPANDER". Figure 3.7a – EXP-33 Expander Module D-306917 PowerMaster-33 G2 Installer's Guide...
  • Page 16 The Speech Box is a wired remote speaker and microphone device for indoor use. It provides two-way voice communication between the user and the central station using the control panel. Caution! Do not install or remove the EXP-33 expander module when the control panel is powered by AC power or battery. D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 17: Le Expander Module Installation

    Caution! Do not install or remove the expander module when the control panel is powered by AC power or battery. D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 18: Connecting Power To The Control Panel

    (B or C) and close the safety cover (D). 4. Connect the power supply output cable (G) to the power connector (H) in the front panel. Figure 3.9a – Power Cable Clamp Extraction and Power Connection for Internal Power Supply D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 19: Battery Insertion

    Figure 3.9c – Battery Insertion 3.9.2 Connect AC Power to the Unit Connect power to the PowerMaster-33 G2 to mains power outlet (see Figures 3.9a and 3.9b). Disregard any “trouble” indications pertaining to lack of battery or lack of telephone line connection.

  • Page 20: Closing The Powermaster-33 G2 Control Panel

    3.10 Closing the PowerMaster-33 G2 Control Panel Control panel final closure is shown below. To Close the Control Panel: 1. Connect the flat cables, between the front and back panel, with the respective connectors. You can have a maximum of 3 connections, depending on the configuration options.

  • Page 21: Visual Indications, First Keypad Enrollment And Using Prox Tag

    Press the ENROLL button for 2 seconds. The Enroll button is physically located inside the front panel of the PowerMaster-33 G2 control panel, see Figure 3.1.1 or 3.1.2 symbol D. If no keypad exists in the first location, the ENROLL LED on the PowerMaster-33 G2 blinks slowly for 1 minute (go to step 3).

  • Page 22: Using Proximity Tags

    5.3 Fuse Replacement The PowerMaster-33 G2 has several internal fuses that reset automatically. Therefore, there is no need to replace the fuses. When over current condition occurs, the fuse cuts off the circuit current. Upon fault current being removed for several seconds, the fuse is automatically reset and allows current flow through the circuit again.

  • Page 23: Appendix A. Specifications

    Up to 1000 events are stored in the event log that can be reviewed via the Remote Programmer PC software application or by the remote PowerManage server. For further information about event log capacity, refer to Chapter 9, Maintenance of the KP-250 PG2. D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 24: A2. Wireless

    450* mA max @ 12.5 VDC when powered by AC/DC (10.5 VDC when in standby mode) (INT) * Total PowerMaster-33 G2 output current (of INT & EXT sirens, PGM output and detectors) cannot exceed 550 mA. Current sink to control panel GND 100 mA max.

  • Page 25: A4. Communication

    Via RS232 serial port Computer Report Destinations 2 Monitoring Stations, 4 private telephones Reporting Format Options SIA, Contact ID, Scancom, SIA IP, Visonic PowerNet. Pulse Rate 10, 20, 33 and 40 pps – programmable Message to Private Phones Tone or voice, SMS...

  • Page 26: A5. Physical Properties

    -4°F to 140°F (-20°C to 60°C) Humidity 85% relative humidity, @ 30°C (86°F) Size (WxHxD) 266 x 201 x 46 mm (10-7/16 x 7-7/8 x 1-13/16 in.) Weight 1.44Kg (3.2 pounds) (with battery) Color White D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 27: A6. Peripherals And Accessory Devices

    Keypad: KP-140 PG2/KP-141 PG2 (with proximity tag), KP-160 PG2, KP-250 PG2 Indoor Siren: SR-720 PG2 Outdoor Sirens: SR-730 PG2, SR-740 PG2, SR-740 HEX PG2 Repeater: RP-600 PG2 Gas: GSD-441 PG2, GSD-442 PG2 Glass-break: GB-501 PG2 Temperature: TMD-560 PG2 Flood: FLD-550 PG2 Shock: SD-304 PG2 D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 28: Appendix B. Compliance With Standards

    II. DD243 and BS8243 Security Grade: Grade 2 Environmental Class: Class II WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. D-306917 PowerMaster-33 G2 Installer's Guide...
  • Page 29 WARRANTY Visonic Limited (the “Manufacturer") warrants this product only (the "Product") to the However, if the Manufacturer is held liable, whether directly or indirectly, for any original purchaser only (the “Purchaser”) against defective workmanship and materials under loss or damage arising under this limited warranty, THE MANUFACTURER'S...
  • Page 30 EMAIL: info@visonic.com INTERNET: www.visonic.com VISONIC LTD. 2017 POWERMASTER-33 G2 Installer's Guide D-306917 Rev 0 (04/17) D-306917 PowerMaster-33 G2 Installer's Guide...

  • Page 31: Operations By Kp-250 Pg2 Keypad

    Quick User Guide to Main Alarm Control Operations by KP-250 PG2 Keypad The Quick Start Guide is intended for the user of the system. Please remove this detachable sheet and hand it to the user. Arming and Disarming the System Step Operation User Actions...

  • Page 32: Preparing To Arm

    Preparing to Arm Before arming, make sure that READY is displayed. HH:MM READY This indicates that all zones are secured and you may arm the system as desired. If at least one zone is open (disturbed) the display will read: HH:MM NOT READY This indicates that the system is not ready for arming and in most cases that one or more zones are not secured.
