Installation

► Video
1. Connect the included DVI cable between the DVI source and DVI In port on the
Sender unit.
2. Connect an DVI display to the DVI Out port on the Receiver unit using another
DVI cable.
► Network cable
3. Connect a shielded CAT-5e (or better) cable, up to 300 feet (100 meters) from the
Link port on the Sender unit to the Link port on the Receiver unit.
► USB
4. Connect the included USB cable from the computer to the USB In port on the Sender
unit.
5. Connect up to three USB devices to the USB ports on the Receiver unit.
Power
►
6. Connect the included 5V DC power supplies to the power receptacles on the Sender
and Receiver unit.
7. Connect the included AC power cords to each power supply and connect both power
cords to available electrical outlets.

Connection Instructions
