CONTENTS Introduction Operation Notes Features Sender Unit Panel Layout Sender Unit Panel Descriptions Receiver Unit Panel Layout Receiver Unit Panel Descriptions 10 Connecting The DVI 1600HD Extender 11 Connecting And Operating The DVI 1600HD Extender 12 Specifi cations 13 Warranty...
Bandwidth Digital Content Protection (HDCP) when the front panel switch on the sender module is selected to HDMI. The Gefen DVI-1600HD uses a DVI connector for video. HDMI can be sent by using adapters or combo cables to provide DVI video with external digital audio as combined input to the DVI-1600HD Sender unit.
OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE DVI 1600HD EXTENDER • DVI 1600HD Extender uses 4 strands of LC terminated f ber optic cable. • Single-mode and multi-mode f ber optic cable types are both supported. • DVI and HDMI modes (for HDCP) are available and are selectable via a switch located on the front panel of the DVI 1600HD sender unit.
• RS232 signal extension helps create long-distance control systems for A/V integration Package Includes (1) Gefen DVI-1600HD Sender (1) Gefen DVI-1600HD Receiver (1) 6 Foot DVI Video Cable (M-M) (1) 6 Foot DB9 RS-232 Cable (M-F) (1) 12V DC Power Supply...
SENDER UNIT PANEL DESCRIPTIONS DVI/HDMI Mode Selector Switch This switch will set the video mode. DVI mode is intended for use with computers and will support resolutions of up to 1920 x 1200. HDMI mode is for use with consumer HDMI devices and supports HDCP and resolutions of up to 1080p Full HD.
Page 9
SENDER UNIT PANEL DESCRIPTIONS 11 12V DC Power Input Connect the included 12V DC power supply to this input. The Power LED will become active when the 12V DC power supply has been properly connected to the unit and an open wall power socket. 12 Analog Stereo Audio Input This input will accept analog stereo audio from one pair or RCA audio cables.
RECEIVER UNIT PANEL DESCRIPTIONS Reset Button This button is used to cycle the power off and on. In most cases this will force the source to re-establish a link with the endpoint device. This will also force the source to re-read the EDID. Optic B LED Indicator This LED will indicate the status of the connection between the sender and receiver’s 2 pair of LC f ber optic cables labeled Optic B.
Page 12
RECEIVER UNIT PANEL DESCRIPTIONS 11 DVI Output This output will accept a DVI or HDMI (with a DVI to HDMI adapter/cable) capable device. 12 Fiber Optic Input A This connector accepts a pair of LC terminated f ber optic cable that will link the sending and receiving unit together.
CONNECTING THE DVI 1600HD EXTENDER How to Connect the DVI 1600HD Extender Connect the DVI or HDMI (using a HDMI to DVI adapter/cable) to the DVI 1600HD Extender sending unit using a user supplied cable. NOTE: If the source device is a HDMI device that requires HDCP, please set the DVI/HDMI mode selector switch to HDMI.
CONNECTING AND OPERATING THE DVI 1600HD EXTENDER How to Connect the DVI 1600HD Extender Connect the included 12V DC power supplies to both the sending and receiving units and open wall power sockets. Power on the endpoint device f rst and then the source device. Operating the DVI 1600HD Extender The DVI 1600HD can be set in either DVI or HDMI mode.
