- Page 1 ® DVI Extra Long Range Extender EXT-DVI-ELR User Manual www.gefen.com...
- Page 3 Notice Gefen LLC reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. DVI Extra Long Range Extender is a trademark of Gefen, LLC © 2013 Gefen LLC, All Rights Reserved.
-
Page 4: Table Of Contents
CONTENTS Introduction Operation Notes Features Sender Unit Layout Sender Unit Descriptions Receiver Unit Layout Receiver Unit Descriptions Connecting the DVI Extra Long Range Extender DIP Switch Configuration 12 Network Cable Wiring Diagram 13 Specifications 14 Warranty... -
Page 5: Introduction
INTRODUCTION Congratulations on your purchase of the Gefen DVI Extra Long Range Extender. Your complete satisfaction is very important to us. Gefen Gefen delivers innovative, progressive computer and electronics add-on solutions that harness integration, extension, distribution and conversion technologies. Gefen’s reliable, plug-and-play products supplement cross-platform computer systems, professional audio/video environments and HDTV systems of all sizes with hard-working solutions that are easy to install and simple to operate. -
Page 6: Operation Notes
NOTE: The shielded cable has an advantage by providing immunity to Electromagnetic Interference (EMI), cell phones and A/C motors. • The Gefen DVI Extra Long Range Extender features the ability to generate compatible EDID and Hot Plug signals when working with different brands of source devices and monitors. -
Page 7: Features
Locking Power Supplies for secure connections • Wall mountable Package Includes (1) Gefen DVI Extra Long Range Extender - Sender Unit (1) Gefen DVI Extra Long Range Extender - Receiver Unit (1) 6 ft. DVI Cable (M-M) (2) 5V DC Locking Power Supplies... -
Page 8: Sender Unit Layout
SENDER UNIT LAYOUT Front Back... -
Page 9: Sender Unit Descriptions
SENDER UNIT DESCRIPTIONS 5 V DC Locking Power Connector Connect the included 5 V DC locking power supply to this connector. Power Indicator This LED will turn bright blue once the included 5 V DC locking power supply has been properly connected to the unit and the locking power supply has been connected to an available electrical outlet. -
Page 10: Receiver Unit Layout
RECEIVER UNIT LAYOUT Front Back... -
Page 11: Receiver Unit Descriptions
RECEIVER UNIT DESCRIPTIONS DVI Out Connect a DVI display to this DVI-I connector. Power Indicator This LED will turn bright blue once the included 5 V DC locking power supply has been properly connected to the unit and the locking power supply has been connected to an available electrical outlet. -
Page 12: Connecting The Dvi Extra Long Range Extender
Unit. Do not overtighten the locking connectors. Plug the two (2) AC power cords from the power supplies to available electrical outlets. Wiring Diagram for the DVI Extra Long Range Extender CAT-5E CABLE (Up To 330 FT) DVI CABLE DVI Source Receiver Sender DVI Display EXT-DVI-ELR... -
Page 13: Dip Switch Configuration
DIP SWITCH CONFIGURATION Sender Unit There are two (2) DIP switches on the bottom of the Sender Unit. At this time, only DIP switch 1 is used on the Sender unit. DIP Switch Function Default Position Green Mode Reserved DIP Switch 1 - Green Mode (Default = ON) •... - Page 14 DIP SWITCH CONFIGURATION Receiver Unit There are four (4) DIP switches on the bottom of the Receiver Unit. These DIP switches allow control over the EDID, HPD (Hot Plug Detect), DVI, and Green mode. DIP Switch Function Default Position EDID Mode HPD Detect DVI Support Green Mode...
- Page 15 DIP SWITCH CONFIGURATION DIP Switch 3* - Supports DVI Connections (Default = ON) • ON - Disable HDCP If HDMI is connected, set DIP 3 in the ON position. • OFF - Enable HDCP If a DVI connection is used, set DIP 3 to the OFF position. DVI is supported by disabling HDCP pass-through.
-
Page 16: Network Cable Wiring Diagram
NETWORK CABLE WIRING DIAGRAM Gefen recommends the TIA/EIA-568-B wiring option. Please adhere to the table below when field terminating cable for use with Gefen products. Color Orange / White Orange Green / White Blue Blue / White Green Brown / White... -
Page 17: Specifications
SPECIFICATIONS Maximum Pixel Clock................165 MHz MaximumTMDS Clock................165 MHz DVI Connector (Sender / Receiver)....DVI-I, 29-pin, female (digital only) Link Connector (Sender / Receiver)...............RJ-45 Power Supply (Sender / Receiver)..............5V DC Power Consumption..............10 W per unit (max.) Operating Temperature................0 - 40 °C Dimensions (W x H x D).....5” x 1.25” x 3.4” (127mm x 31.75mm x 86.36mm) Shipping Weight:................4 lbs. -
Page 18: Warranty
If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. - Page 20 Rev A3 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com This product uses UL listed or CE compliant power supplies.
