DVI FM 2000 0
DVI FM 2000
0
EXT-DVI-FM2000
User Manual
www.gefen.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXT-DVI-FM2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Gefen EXT-DVI-FM2000

Summary of Contents for Gefen EXT-DVI-FM2000

  • Page 1 DVI FM 2000 0 DVI FM 2000 EXT-DVI-FM2000 User Manual www.gefen.com...
  • Page 2 Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. DVI FM 2000 Extender is a trademark of Gefen, LLC © 2011 Gefen, LLC All Rights Reserved...

  • Page 3: Table Of Contents

    CONTENTS Introduction Operation Notes Features Sender Unit Layout Sender Unit Descriptions Receiver Unit Layout Receiver Unit Descriptions Connecting the DVI FM 2000 Wiring Diagram Specifications Warranty...

  • Page 4: Introduction

    The Gefen DVI FM 2000 The Gefen DVI FM 2000 extends a Dual Link DVI source up to 1000 feet (300 meters) using multi-mode (50 micron) fi ber optic cable. Resolutions up to 1080p Full HD and 2560 x 1600 at 60 Hz are supported.

  • Page 5: Operation Notes

    OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE DVI DUAL LINK FIBER EXTENDER • The DVI Dual Link Fiber Extender only uses multi-mode SC fi ber cables. ATTENTION: Multi-mode fi ber optic cable with a core diameter of 50/125 is required, in order to extend to distance of 1000 feet (300 meters).

  • Page 6: Features

    FEATURES Features • Extends Dual Link DVI up to 1000 feet (300 meters) using multi-mode (50/125) fi ber optic cable. • Supports HD resolutions up to 1080p Full HD. • Supports VESA resolutions up to 1920 x 1200 (WUXGA) @ 60 Hz and 2560 x 1600 (WQXGA) @ 60 Hz.

  • Page 7: Sender Unit Layout

    SENDER UNIT LAYOUT Front Back Back...

  • Page 8: Sender Unit Descriptions

    SENDER UNIT DESCRIPTIONS Status This LED indicator will glow bright blue, indicating that there is a valid connection between the Sender Unit and Receiver Unit. This LED will glow red when there is an interruption in the signal between the Sender Unit and the Receiver Unit.

  • Page 9: Receiver Unit Layout

    RECEIVER UNIT LAYOUT Front Back Back...

  • Page 10: Receiver Unit Descriptions

    RECEIVER UNIT DESCRIPTIONS Status This LED indicator will glow bright blue, indicating that there is a valid connection between the Receiver Unit and Sender Unit. This LED will glow red when there is an interruption in the signal between the Receiver Unit and the Sender Unit.

  • Page 11: Connecting The Dvi Fm 2000

    CONNECTING THE DVI FM 2000 How to Connect the DVI FM 2000 Connect the Dual Link DVI source to the Sender Unit. Connect the Dual Link DVI display to the Receiver Unit. Connect the Sender Unit and Receiver unit together using two SC multi-mode fi...

  • Page 12: Wiring Diagram

    WIRING DIAGRAM Wiring Diagram for the DVI FM 2000 SC FIBER OPTIC CABLE Sender DVI Source Receiver DVI Display EXT-DVI-FM2000 ATTENTION: This product should always be connected to a grounded electrical socket.

  • Page 13: Specifications

    SPECIFICATIONS Maximum Pixel Clock........................2 x 165 MHz Input Video Signal........................1.2 volts p-p Input DDC Signal........................5 volts p-p (TTL) DVI Connector (Sender / Receiver)................DVI-D, 19-pin, male Fiber Optic Connector (Sender / Receiver)..................SC type Power Supply (Sender / Receiver).....................5V DC Power Consumption....................2.5 Watts (max.) per unit Operating Temperature........................0 ~ 50 °C Storage Temperature.........................

  • Page 14: Warranty

    Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
  • Page 15 Rev A1 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com This product uses UL listed power supplies.
