Gefen EXT-DVIKVM-ELR User Manual page 15

1 2
EXT-DVIKVM-ELRR
Service
Link
ID Name
1 SERVICE
2 LINK
3 DVI Out
4 USB
5 5V DC
DVI KVM ELR Extender over one CAT-5 R
®
3
DVI Out
Description
Mini-USB port for factory use only.
Connects the Receiver unit to the Sender
unit using shielded CAT-5e (or better) cable.
2 E
Connect a DVI cable from this connector to
the DVI display.
Use these ports to connect up to three USB
devices.
Connect the included 5V DC locking power
supply to this power receptacle.
page | 5
Introduction
Link
Power USB
4 5
USB 5V DC
