- Page 1 DVI FM1000 Extender EXT-DVI-FM-1000 User Manual User Manual www.gefen.com...
- Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying DVI FM1000 Extender is a trademark of Gefen Inc. All trademarks are the property of their respective companies Notice doc u men ta tion without prior written notice.
-
Page 3: Table Of Contents
Introduction Operation Notes Features Panel Layout Connecting And Operating The DVI FM1000 Extender Specifi cation Warranty CONTENTS... -
Page 4: Introduction
The Gefen DVI FM1000 Extender The DVI-FM1000 Extender extends your DVI display up to 3,280 feet (1km) away from your video source, with only two tiny transceivers required, using a 100% optical SC fi ber solution with a single strand of fi... -
Page 5: Operation Notes
READ THESE NOTES BEFORE INSTALLING OR OPERATING THE DVI FM1000 EXTENDER • DVI FM1000 Extender can only be operated with multi-mode SC terminated fi ber optic cable. • The supplied power adapter must only be used on the receiving unit. Power for the transmitting unit is supplied by the source device. -
Page 6: Features
Features • Extends any DVI (Digital Visual Interface)-compliant device up to 3,280 ft (1km) from the computer • Supports video resolutions up to 1080p, 2K, and 1920 x 1200 • Uses inexpensive and widely available single-strand multimode SC fi ber optic cable •... -
Page 7: Panel Layout
PANEL LAYOUT Sender Front Panel DVI In Sender Back Panel Sender Back Panel Optical 5V DC Cable Input Input Receiver Front Panel DVI Out Receiver Back Panel Receiver Back Panel Optical Cable Input 5V DC Input... -
Page 8: Connecting And Operating The Dvi Fm1000 Extender
CONNECTING AND OPERATING THE DVI FM1000 EXTENDER How to Connect the DVI FM1000 Extender EDID Recording Display information (EDID) contains resolution and timing information for your display. This information is needed by the source for proper video output. Follow these steps to record the EDID of the display into the sending unit. If you know that EDID is not required by the source the followings steps for recording will not be necessary. -
Page 9: Specifications
SPECIFICATIONS Video Amplifi er Bandwidth ... 165 MHz (Single Link) Input Video Signal ... 1.2 Volts p-p Input DDC Signal ... 5 Volts p-p (TTL) DVI Connector ... Type DVI-D (19 pin) male Link Connector ... SC Power Supply ... 5V DC Power Consumption ...
