Installation

► Video
1. Connect the included HDMI cable between the HD source and HDMI In port on the
Sender unit.
2. Connect an HD display to the HDMI Out port on the Receiver unit using another
HDMI cable.
► Network cable
3. Connect a shielded CAT-5e (or better) cable, up to 300 feet (100 meters) from the
Link port on the Sender unit to the Link port on the Receiver unit.
► USB
4. Connect the included USB cable from the computer to the USB In port on the Sender
unit.
5. Connect up to three USB devices to the USB ports on the Receiver unit.
Power
►
6. Connect the included 5V DC power supplies to the power receptacles on the Sender
and Receiver unit.
7. Connect the included AC power cords to each power supply and connect both power
cords to available electrical outlets.
