6
MENU SCREEN
■ Function (Continued)
Earphone Antenna ( ~ 1.3G)
[MENU] > Function > Earphone Antenna ( ~ 1.3G)
Select whether or not to use the earphone cable connected to the receiver as an
antenna.
• Not Used: Does not use the earphone cable as an antenna.
• Use: Uses the earphone cable as an antenna.*
*The external antenna is also used.
CI-V Address
[MENU] > Function > CI-V > CI-V Address
To distinguish equipment, each CI-V receiver or transceiver has its own Icom standard
address in hexadecimal code. The receiver's default address is 9C.
When 2 or more receivers are controlled through a PC at the same time, set a different
address for each receiver.
CI-V Baud Rate
[MENU] > Function > CI-V > CI-V Baud Rate
Set the CI-V data transfer speed to 4800, 9600, 19200 bps, or Auto.
L When "Auto" is selected, the baud rate is automatically set, according to the data rate of
the controller.
CI-V Transceive
[MENU] > Function > CI-V > CI-V Transceive
Turn the CI-V Transceive function ON or OFF.
OFF: Turns OFF the function.
ON: When you change a setting on one receiver, the same settings is automatically
changed on other connected transceivers or receivers.
CI-V USB/Bluetooth -> REMOTE Transceive Address
[MENU] > Function > CI-V > CI-V USB/Bluetooth -> REMOTE Transceive Address
Set the address.
If you remotely operate using a USB cable or Bluetooth when CI-V Transceive is set
to "ON," the device in the same system is externally controlled through the Speaker
(REMOTE) jack.
Enter an address between 00 and DF (hexadecimal).
L Set other address than "00" to prohibit the external control by a third-party receiver.
L The control signal is output from the [SP] jack.
6-20
(Default: Not Used)
(Default: 9C)
(Default: Auto)
(Default: OFF)
(Default: 00)
