7
OTHER FUNCTIONS
■ Cloning function (Continued)

D Cloning from a PC using a microSD card

You can clone receivers from a PC using a microSD card.
1. Connect the receiver and a PC using the supplied USB cable.
2. Turn ON the receiver power.
3. Push [MENU].
4. Select "USB Connect" in the "Function" menu.
(Rotate [DIAL] to select it, then push [ENTER].)
• A confirmation dialog appears.
5. Select "SD Card Mode."
6. Select "YES," and then push [ENTER].
• Displays the IC-R30 folder on the PC screen.
7. Save the setting data as an "icf" file, then put it into the "Setting" folder in the "IC-
R30" folder on the microSD card.
8. Perform the SD card removal on the PC.
9. Insert the microSD card that includes the "icf" file, then load it to complete the
cloning.
microSD card configuration
IC-R30
Connections
Csv GpsMemory
Gps MemoryCh
RxLog ScanEdge
Setting
Voice yyyymmdd
yyyymmdd
Supplied USB cable
IC-R30 is recognized
as a USB flash drive
Put in the icf file
To a USB port
7-28
