D Making A Backup File On A Pc - Icom IC-R30 Advanced Manual

2
microSD Card
■ Backing up the data stored on the microSD card onto a PC (Continued)
D Making a backup fi le on a PC
You can make a backup of the data that is stored on a microSD card, through a USB
cable.
Operation on the receiver
[MENU] > Function > USB Connect > SD Card Mode
1. Connect the receiver to a PC using a USB cable.
2. Turn ON the receiver power.
3. Push [MENU].
4. Select "SD Card Mode" in the "Function" menu.
(Rotate [DIAL] to select it, then push [ENTER].)
• A confi rmation dialog appears.
5. Select "YES."
• Displays the IC-R30 folder on the PC screen.
TIP: You can also read or write the data using the microSD card and a card reader
(user supplied), without a USB cable. Remove the microSD card that contains the data
from the IC-R30, then read it on the PC using the card reader.
2-6
