2. Specifications

2.1. USB Specification

•
USB 2.0 compliant.
•
Bus powered: requires +5V DC power from the driving port.
•
Maximum USB cable length: 16 feet (from USB 2.0 spec).
•
USB signal and shield grounded to power supply chassis.

2.2. Rear Panel Specifications

•
"B" Type USB socket, four pins.
•
DIP switch to enable or disable the USB port.
•
Enable USB. Also disables RS-232 and RS-485 IN.
•
Disable USB. Allows RS-232 and RS-485 with daisy chaining.
•
All other rear panel features are the same as the standard Genesys™ power supply.

2.3. Front Panel Specifications

•
On power-up, when USB is enabled, front panel shows "USb" for three seconds.
•
Settable serial address (0 to 30) for daisy-chaining many supplies to one USB port.
•
All other front panel features are the same as the standard Genesys™ power supply.

2.4. USB Drivers

•
Most common drivers available on the Genesys™ Driver CD-ROM.
•
Additional drivers available for download from
•
Support for a variety of operating systems: Windows, Mac OS, Linux and Windows CE.

2.5. Software Support

•
The USB power supply may be installed as a Virtual COM port (VCP). This allows the USB supply to
appear as an additional COM port (i.e. RS-232 port) available to the PC. Application software can
access the USB supply in the same way as it would access a standard COM port.
•
There is full support for COM ports including:
•
You may send commands with programs such as HyperTerminal.
•
Any programming language may use the native operating system drivers for the COM port.
•
TDK-Lambda has Test and Measurement drivers including IVI-COM, IVI-C and native LabView.
•
There is a USB driver library (DLL) called D2XX drivers. These allow your application program can make
direct communication to the Genesys™ USB without creating a virtual COM port.
•
There is support for the USB D2XX driver library including:
•
The library drivers are available on the Genesys™ Driver CD-ROM.
•
Library compatible with Windows, Mac OS and Linux.
•
See http://www.ftdichip.com

2.6. USB Command Set

•
Uses serial command set with abbreviated commands. For example, send "PV" to program the voltage.
•
Uses same commands as the standard Genesys™ power supply for RS-232/485.
•
Commands are not SCPI compliant.
http://www.ftdichip.com.
for additional support.
