Step
3. Configure Anycast RP.

Configuring a BSR

You must configure a BSR if C-RPs are configured to dynamically select the RP. In a network with a static
RP, this configuration task is unnecessary.
A PIM-SM domain can have only one BSR, but must have at least one C-BSR. Any router can be
configured as a C-BSR. Elected from C-BSRs, the BSR is responsible for collecting and advertising RP
information in the PIM-SM domain.
Configuring a C-BSR
C-BSRs should be configured on routers on the backbone network. The BSR election process is
summarized as follows:
1. Initially, each C-BSR regards itself as the BSR of the PIM-SM domain and sends BSMs to other
routers in the domain.
2. When a C-BSR receives the BSM from another C-BSR, it compares its own priority with the priority
carried in the message. The C-BSR with a higher priority wins the BSR election. If a tie exists in the
priority, the C-BSR with a higher IP address wins. The loser uses the winner's BSR address to
replace its own BSR address and no longer regards itself as the BSR. The winner retains its own
BSR address and continues to regard itself as the BSR.
In a PIM-SM domain, the BSR does the following:
Collects C-RP information from the received advertisement messages from the C-RPs.
•
Encapsulates the C-RP information in the RP-set information.
•
• Distributes the RP-set information to all routers in the PIM-SM domain.
All routers use the same hash algorithm to get an RP for a specific multicast group.
Configuring a legal BSR address range enables filtering of BSMs based on the address range, which
prevents a maliciously configured host from masquerading as a BSR. The same configuration must be
made on all routers in the PIM-SM domain. The following describes the typical BSR spoofing cases and
the corresponding preventive measures:
Some maliciously configured hosts can forge BSMs to fool routers and change RP mappings. Such
•
attacks often occur on border routers. A BSR is inside the network and receiver hosts are outside the
network. To protect a BSR against external attacks, you can enable the border routers to do the
following:
Perform neighbor checks and RPF checks on BSMs.
Discard unwanted messages.
When an attacker controls a router on the network, the attacker can configure the router as a C-BSR
•
to win the BSR election. Through this router, the attacker controls the advertising of RP information.
For security purposes, you can configure a legal BSR address range on all routers on the network.
All routers will discard BSMs that are out of the legal address range.
Command
anycast-rp anycast-rp-address
member-rp-address
99
Remarks
By default, Anycast RP is not
configured. You can repeat this
command to add multiple RP
member addresses to the Anycast
RP set.
