Chapter 3: Jumpers and Switches
Mini-PCIe (USB + PCIe)
Connector location: CN27
SIM Socket: SIM 2 (default)
SIM Socket: SIM 3
1 2
51 52
Pin Definition
1 PCIE_Wake#2
3 NC
5 NC
7 PCIE_CLKREQ#2
9 GND
11 PCIE_CLKN2
13 PCIE_CLKP2
15 GND
17 NC
19 NC
21 GND
23 PCIE_RXN2
25 PCIE_RXP2
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 3.3VSB_3
4 GND
6 1.5V_3
8 UIM_PWR
10 UIM_DATA
12 UIM_CLK
14 UIM_RESET
16 NC
18 GND
20 3.5GDIS#
22 3.5GRST#
24 3.3VSB_1
26 GND
Pin Definition
27 GND
29 GND
31 PCIE_TXN2
33 UMTS_RESET#_R
35 GND
37 GND
39 3.3VSB_4
41 3.3VSB_5
43 GND
45 NC
47 NC
49 NC
51 NC
29
Pin Definition
28 1.5V_2
30 SMBCLK
32 SMBDAT
34 GND
36 USB_D-
38 USB_D+
40 GND
42 LED_WWAN#
44 LED_WLAN#
46 NC
48 1.5V_1
50 GND
52 3.3VSB_2
