Chapter 3: Jumpers and Switches

SATA HDD Connector

Connector size: CN7, 1 x 4 = 4-pin header (2.54mm)
CN9 1 x 7 = 7-pin header (1.27mm)
Connector location: CN7 & CN9
1 4
CN7
Pin Definition
1 VCC12
3 GND
1 7
CN9
Pin Definition
1 GND
3 SATA_TXN0
5 SATA_RXN0
7 GND
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 GND
4 VCC5
Pin Definition
2 SATA_TXP0
4 GND
6 SATA_RXP0

Debug Port

Connector size: 1 x 3 = 3-pin header (2.54mm)
Connector location: JP2
1 3
Pin Definition
1 TX
2 RX
3 GND
24
