Chapter 3: Jumpers and Switches

Mini-PCIe (USB)

Connector location: CN26
SIM Socket: SIM 1 (default)
SIM Socket: SIM 2
1 2
51 52
Pin Definition
1 MINI_MIC_P
3 MINI_MIC_N
5 MINI_SPK_PRR
7 U_GND
9 GND
11 VCC_MSM26_DIG
13 NC
15 GND
17 NC
19 NC
21 GND
23 NC
25 NC
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 +V3.3A_MINI_4
4 GND
6 NC
8 UIM_PWR2
10 UIM_DAT2
12 UIM_CLK2
14 UIM_RST2
16 NC
18 GND
20 3.5G_DIS#
22 3.5G_RST#
24 +V3.3A_MINI_4
26 GND
Pin Definition
27 GND
29 GND
31 NC
33 UMTS_RESET#_R
35 GND
37 GND
39 +V3.3A_MINI_4
41 +V3.3A_MINI_4
43 GND
45 PCM_CLK
47 PCM_RX
49 PCM_TX
51 PCM_SYNC
28
Pin Definition
28 NC
30 NC
32 SMS_RI_3.5G_R
34 GND
36 USB-
38 USB+
40 GND
42 3.5G_LED#_R
44 NC
46 NC
48 NC
50 GND
52 +V3.3A_MINI_4
