Table 6-15. Connector J23 Signal Description for a Large LCD Extension
Pin
25
27
29
31
33
35
37
39
Table 6-16. Connector J18 Signal Description for a Large LCD Extension
Pin
1
3
5
7
9
11
13
15
17
19
AT91SAM9G45-EKES User Guide
Mnemonic
PE4 LCDHSYNC
PE5 LCDDOTCK
GND (0V)
PE6 LCDDEN
PE0 DISPON
PD14 GPIO1
GND (0V)
VCC +3V3 power source
Mnemonic
XM AD1XM
YM AD3YM
GND (0V)
PD25 PD25
PD27 PD27
PD19 PD19
GND (0V)
GND (0V)
GND (0V)
VCC +3V3 power source
Pin
26 PE3 LCDVSYNC
28 GND (0V)
30 NC
32 PE2 LCDCC
34 PE1 LCDMOD
36 PD15 GPIO2
38 GND (0V)
40 NC
Pin
2 XP AD0XP
4 YP AD2YP
6 GND (0V)
8 PD24 PD24
10 PD26 PD26
12 PD18 PD18
14 GND (0V)
16 +5V
18 GND (0V)
20 VCC +3V3 power source
Connectors
Mnemonic
Mnemonic
6-11
