Connectors
6.8
SD/MMC- MCI0
Connector J6 is the SD/MMC connector.
Figure 6-8.
Table 6-8. SD/MMC0 Connector J6 Signal Descriptions
Pin
1
3
5
7
9
11
6-6
6481B–ATARM–27-Nov-09
SD/MMC0 Connector J6
Mnemonic
Pin
RSV/DAT3
2
GND
4
CLK
6
DAT0
8
DAT2
10
GND
12
Mnemonic
CDA
VCC
GND
DAT1
Card Detect
AT91SAM9G45-EKES User Guide
