Image Sensor - Isi - Atmel AT91SAM9G45-EKES User Manual

Connectors
Table 6-11. Speaker JP15 Signal Descriptions
Pin
6.11

Image Sensor - ISI

Connector J17 is the ISI connector.
Figure 6-11. ISI Connector J17
Table 6-12. ISI Connector J17 Signal Descriptions
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
6-8
6481B–ATARM–27-Nov-09
Mnemonic
1 Speaker bridge output A
2 Speaker bridge output B
Mnemonic Pin
VCC 3v3
VCC 3v3
Ctrl1
SCL
Gnd 10
Gnd 12
Gnd 14
Gnd 16
Gnd 18
ISI_Data1 20
ISI_Data3 22
ISI_Data5 24
ISI_Data7 26
ISI_Data9 28
ISI_Data11 30
Mnemonic
2 Gnd
4 Gnd
6 Ctrl2
8 SDA
ISI_MCK
ISI_VSYNC
ISI_HSYNC
ISI_PCK
ISI_Data0
ISI_Data2
ISI_Data4
ISI_Data6
ISI_Data8
ISI_Data10
Gnd
