Configuration
5.5.6

Multiplexing on PIO Controller E (PIOE)

Table 5-8. PIO Multiplexing Port E
I/O Peripheral A
PE0 LCDPWR
PE1 LCDMOD
PE2 LCDCC
PE3 LCDVSYNC
PE4 LCDHSYNC
PE5 LCDDOTCK
PE6 LCDDEN
PE7 LCDD0
PE8 LCDD1
PE9 LCDD2
PE10 LCDD3
PE11 LCDD4
PE12 LCDD5
PE13 LCDD6
PE14 LCDD7
PE15 LCDD8
PE16 LCDD9
PE17 LCDD10
PE18 LCDD11
PE19 LCDD12
PE20 LCDD13
PE21 LCDD14
PE22 LCDD15
PE23 LCDD16
PE24 LCDD17
PE25 LCDD18
PE26 LCDD19
PE27 LCDD20
PE28 LCDD21
PE29 LCDD22
PE30 LCDD23
PE31 PWM2
5-8
6481B–ATARM–27-Nov-09
Peripheral B
PCK0
LCDD2
LCDD3
LCDD4
LCDD5
LCDD6
LCDD7
LCDD10
LCDD11
LCDD12
LCDD13
LCDD14
LCDD15
LCDD18
LCDD19
LCDD20
LCDD21
LCDD22
LCDD23
PCK1
Function and Comments
LCD Panel Pow.Enab.Ctrl
LCD Modulation Signal
LCD Contrast Control
LCD Vertical Synch.
LCD Horizontal Synch.
LCD Dot Clock
LCD Data Enable
LCD-Red0
LCD-Red1
LCD-Red2
LCD-Red3
LCD-Red4
LCD-Red5
LCD-Red6
LCD-Red7
LCD-Green0
LCD-Green1
LCD-Green2
LCD-Green3
LCD-Green4
LCD-Green5
LCD-Green6
LCD-Green7
LCD-Blue0
LCD-Blue1
LCD-Blue2
LCD-Blue3
LCD-Blue4
LCD-Blue5
LCD-Blue6
LCD-Blue7
AC97 External Clock
Power
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
VDDIOP1
