6.12

Video

Connector J20 is the Video connector
Figure 6-12. Video Connector J20
Table 6-13. Video Connector J20 Signal Description
Pin
6.13

Display Devices

6.13.1

LG TFT LCD LG/PHILIPS

Connector J24 is the TFT-LCD connector.
Figure 6-13. TFT LCD Connector J24
Table 6-14. LG TFT LCD Connector J24 Signal Descriptions
Pin
AT91SAM9G45-EKES User Guide
Mnemonic
1
Center
Mnemonic
1
GND
3
VDD 3V3
5
R0
7
R2
9
R4
Signal description
Composite video signal output
Pin
Mnemonic
2
GND
4
VDD 3V3
6
8
10
R1
R3
R5
Connectors
6-9
6481B–ATARM–27-Nov-09
