Figure 4-9.
4.2.6.5 Ethernet 10/100 (EMAC) Port
The port is compatible with IEEE
The SAM9G45-EKES is equipped with a Davicom DM9161AEP 10/100 Mbps Fast Ethernet Physical
Layer TX/FX Single Chip Transceiver. It contains the entire physical layer functions of 100BASE-TX as
defined by IEEE 802.3u, including the Physical Coding Sublayer (PCS), Physical Medium attachment
(PMA), Twisted Pair Physical Medium Dependent Sublayer (TP-PMD), 10BASE-TX Encoder/Decoder
(ENC/DEC), and Twisted Pair Media Access Unit (TPMAU).
The Ethernet interface integrates an RJ45 connector with an embedded transformer, and three status
LEDs.
The Ethernet interface provides two selectable modes, MII or RMII (Reduced MII), for 100Base-Tx or
10Base-Tx. The MII and RMII interfaces are capable of both 10Mb/s and 100Mb/s data rates as
described in the IEEE 802.3u standard. The signals used by MII and RMII interfaces are described in the
table below.
AT91SAM9G45-EKES User Guide
USB Port
J12 J12
292303-1 292303-1
1 2
4 3
C162 C162
100nF 100nF
5 6
L15 L15
BLM21PG221SN1x BLM21PG221SN1x
C164 C164
33 uF 33 uF
16V 16V
L16 L16
BLM21PG221SN1x BLM21PG221SN1x
C165 C165
33 uF 33 uF
16V 16V
ZX62-AB-5P ZX62-AB-5P
7
1
VBUS VBUS
2
DM DM
3
DP DP
4
ID ID
5
GND GND
6
J14 J14
C167 C167
100nF 100nF
®
USB HOST INTERFACE
5V
C163 C163
100nF 100nF
R88 R88 47K 47K
(VBUS)
PB19
R89 R89
C166 C166 68K 68K
10pF 10pF
USB HOST/DEVICE INTERFACE
Standard 802.3.
Board Description
MN20 MN20
8 1 (ENA)
OUTA ENA
7 2 (FLGA)
IN FLGA
6 3
(FLGB)
GNG FLGB
5 4 (ENB)
OUTB ENB
SP2526A-2 SP2526A-2
3V3
R90 R90
47K 47K
(IDUSB)
HDMA
HDPA
PD1
PD2
PD4
PD3
HDMB
HDPB
PD28
4-11
6481B–ATARM–27-Nov-09
