  • Page 1 AT91SAM7SE-EK Evaluation Board ....................User Guide...
  • Page 2 AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 3: Table Of Contents

    Table of Contents Section 1 Overview....................1-1 Scope......................1-1 Deliverables ....................1-1 AT91SAM7SE-EK Evaluation Board ............1-1 Section 2 Setting Up the AT91SAM7SE-EK Board ..........2-1 Electrostatic Warning ................2-1 Requirements....................2-1 Layout .......................2-2 Powering Up the Board ................2-3 Getting Started..................2-3 AT91SAM7SE-EK Block Diagram ............2-4 Section 3 Board Description .................
  • Page 4 Section 5 Schematics ................... 5-1 Schematics ....................5-1 Section 6 Errata ....................6-1 PIO Usage ....................6-1 TWI line pullups are too weak for Fast Mode operation......6-1 Section 7 Revision History..................7-1 Revision History ..................7-1 AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 5: Overview

    Section 1 Overview Scope The AT91SAM7SE-EK evaluation board enables the evaluation of and code develop- ment for applications running on an AT91SAM7SE device. This guide focuses on the AT91SAM7SE-EK board as an evaluation platform. Deliverables 1.2.1 Standard Version The AT91SAM7SE-EK package contains the following items:...
  • Page 6 ! One power LED and two general-purpose LEDs ! One joystick and two user input pushbuttons ! One Reset pushbutton ! Three expansion connectors (PIO A, PIO B, PIO C) ! One EBI expansion BGA-like footprint connector AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 7: Setting Up The At91Sam7Se-Ek Board

    Avoid touching the component pins or any other metallic element. Requirements In order to set up the AT91SAM7SE-EK evaluation board, the following items are needed: ! The AT91SAM7SE-EK evaluation board itself.

  • Page 8: Layout

    Setting Up the AT91SAM7SE-EK Board Layout Figure 2-1. AT91SAM7SE-EK Layout - Top View AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 9: Powering Up The Board

    Setting Up the AT91SAM7SE-EK Board Figure 2-2. AT91SAM7SE-EK Layout - Bottom View Powering Up the The AT91SAM7SE-EK requires 5V DC (±5%). DC power is supplied to the board via the 2.1 mm x 5.5 mm socket J1. Coaxial plug center positive standard. Board...

  • Page 10: At91Sam7Se-Ek Block Diagram

    Setting Up the AT91SAM7SE-EK Board AT91SAM7SE-EK Block Diagram MEMORY POWER SUPPLY D[0..31] PWM0 D[0..15] POWERLED D[0..15] A[0..22] A[2..14] A[2..14] PWM1 USERLED1 PWM2 SDA10 USERLED2 SDA10 SDWE SDWE SDCS SDCS PB22 RIGHTCLIC SDCK SDCK SDCK PB23 SDCKE SDCKE PB24 DOWN PB27...

  • Page 11: Board Description

    – Based on Power-on Reset Cells and Low-power Factory-calibrated Brownout Detector – Provides External Reset Signal Shaping and Reset Source Status • Clock Generator (CKGR) – Low-power RC Oscillator, 3 to 20 MHz On-chip Oscillator and One PLL • Power Management Controller (PMC) AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...
  • Page 12 – Double PWM Generation, Capture/Waveform Mode, Up/Down Capability • One Four-channel 16-bit PWM Controller (PWMC) • One Two-wire Interface (TWI) – Master, Multi-Master and Slave Mode Support, All Two-wire Atmel EEPROMs Supported – General Call Supported in Slave Mode • One 8-channel 10-bit Analog-to-Digital Converter, Four Channels Multiplexed with Digital I/Os ™...
  • Page 13 – 1.8V VDDCORE Core Power Supply with Brownout Detector • Fully Static Operation: Up to 48 MHz at 1.65V and 85° C Worst Case Conditions • Available in a 128-lead LQFP Green Package, or a 144-ball LFBGA RoHS-compliant Package AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 14: At91Sam7Se Block Diagram

    NPCS3 Controller NCS6/CFCE2 MISO NCS7 MOSI SPCK NANDOE NANDWE TCLK0 NWAIT Timer Counter TCLK1 SDCK TCLK2 Controller TIOA0 TIOB0 TIOA1 FIFO TIOB1 TIOA2 USB Device TIOB2 ADTRG PWM0 PWM1 PWMC PWM2 PWM3 ADVREF TWCK AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 15: Memory

    ! One additional serial interface (COM Port 0) with RTS/CTS handshake control via RS-232 DB9 male connectors ! USB V2.0 Full-speed compliant, 12 Mbits per Second (UDP) ! One Atmel stereo audio DAC (AT73C213) Audio Stereo Interface ! One 32 Ohm/20 mW Stereo Headset output (J3) with master volume and mute...

  • Page 16: Pio Usage

    NWR1_NBS1_CFIOR SDRAM DEVICE (NBS1) PA24 RTS1 SDA10 SDRAM DEVICE (SDA10) PA25 CTS1 SDCKE SDRAM DEVICE (SDCKE) PA26 DCD1 NCS1_SDCS SDRAM DEVICE (Chip Select) PA27 DTR1 SDWE SDRAM DEVICE (SDWE) PA28 DSR1 SDRAM DEVICE (CAS) AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...
  • Page 17 PCK1 PB22 NPCS3 RIGHT clic push button PB23 PWM0 Joystick UP PB24 PWM1 Joystick DOWN PB25 PWM2 Joystick LEFT PB26 TIOA2 Joystick RIGHT PB27 TIOB2 Joystick PUSH and LEFT clic push button PB28 TCLK1 AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...
  • Page 18 NPCS1 PC15 NCS3_NANDCS PC16 NWAIT PC17 NANDOE NandFlash (NANDOE) PC18 NANDWE NandFlash (NANDWE) PC19 USB_CNX (VBUS DETECT) and NandFlash (ALE). See errata section PC20 NCS7 NandFlash (CLE) PC21 NWR0_NWE_CFWE PC22 NRD_CFOE PC23 CFRNW NCS0 AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 19: Configuration

    To use this feature, the user has to open the strap and insert an anmeter. Audio Configuration Table 4-2. Audio Configuration Default Designation Setting Feature Soldered Enables the use of the audio stereo DAC AT73C213 AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 20: Jtag/Ice

    Enables SCL access Soldered Enables SDA access Ethernet NOT POPULATED Table 4-6. Ethernet Configuration Default Designation Setting Feature Soldered Enables the use of the Ethernet controller DM9000A Soldered Enables the use of the IRQ Ethernet controller AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 21: Miscellaneous

    Soldered RTS0 RS232 COM Port 0: Enable the use of input signals RXD0 Soldered CTS0 GND Test point GND Test point. GND Test point. GND Test point. Refer to Section 2.6, “AT91SAM7SE-EK Block Diagram”. AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...
  • Page 22 Configuration AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 23: Schematics

    Schematics This section contains the following schematics: ! Board Layout And Silkscreen Printing - Top View ! Power & Audio & User Interface ! AT91SAM7SE512-LQFP128 ! Memory ! Ethernet ! Serial Interface ! Expansion AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...
  • Page 24 DES. DES. DES. DATE DATE DATE VER. VER. VER. DATE DATE DATE PA31 NPCS1 PB31 PCK2 PA31 AT91SAM7SE-EK AT91SAM7SE-EK AT91SAM7SE-EK SCALE SCALE SCALE REV. REV. REV. SHEET SHEET SHEET DIAGRAM DIAGRAM DIAGRAM This agreement is our property. Reproduction and publication without our written authorization shall expose offender to legal proceedings.
  • Page 25 MODIF. MODIF. DES. DES. DES. DATE DATE DATE VER. VER. VER. DATE DATE DATE AT91SAM7SE-EK AT91SAM7SE-EK AT91SAM7SE-EK SCALE SCALE SCALE REV. REV. REV. SHEET SHEET SHEET POWER & AUDIO & UI POWER & AUDIO & UI POWER & AUDIO & UI This agreement is our property.
  • Page 26 MODIF. MODIF. MODIF. DES. DES. DES. DATE DATE DATE VER. VER. VER. DATE DATE DATE AT91SAM7SE-EK AT91SAM7SE-EK AT91SAM7SE-EK SCALE SCALE SCALE REV. REV. REV. SHEET SHEET SHEET AT91SAM7SE512-LQFP128 AT91SAM7SE512-LQFP128 AT91SAM7SE512-LQFP128 This agreement is our property. Reproduction and publication without our written authorization shall expose offender to legal proceedings.
  • Page 27 DES. DES. DES. VER. VER. VER. MODIF. MODIF. MODIF. DATE DATE DATE DATE DATE DATE AT91SAM7SE-EK AT91SAM7SE-EK AT91SAM7SE-EK SCALE SCALE SCALE REV. REV. REV. SHEET SHEET SHEET MEMORY MEMORY MEMORY This agreement is our property. Reproduction and publication without our written authorization shall expose offender to legal proceedings.
  • Page 28 MODIF. MODIF. MODIF. DES. DES. DES. DATE DATE DATE VER. VER. VER. DATE DATE DATE AT91SAM7SE-EK AT91SAM7SE-EK AT91SAM7SE-EK SCALE SCALE SCALE REV. REV. REV. SHEET SHEET SHEET ETHERNET ETHERNET ETHERNET This agreement is our property. Reproduction and publication without our written authorization shall expose offender to legal proceedings.
  • Page 29 MODIF. MODIF. MODIF. DES. DES. DES. DATE DATE DATE VER. VER. VER. DATE DATE DATE AT91SAM7SE-EK AT91SAM7SE-EK AT91SAM7SE-EK SCALE SCALE SCALE REV. REV. REV. SHEET SHEET SHEET SERIAL INTERFACES SERIAL INTERFACES SERIAL INTERFACES This agreement is our property. Reproduction and publication without our written authorization shall expose offender to legal proceedings.
  • Page 30 DATE DATE DATE VER. VER. VER. DATE DATE DATE SCALE SCALE SCALE AT91SAM7SE-EK AT91SAM7SE-EK AT91SAM7SE-EK REV. REV. REV. SHEET SHEET SHEET EXPANSION EXPANSION EXPANSION This agreement is our property. Reproduction and publication without our written authorization shall expose offender to legal proceedings.
  • Page 31 Schematics AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 32: Errata

    Note that there is no need to change the pull-up resistors if the TWI is used in Standard Mode (up to 100 Kbits/s). AT73C213 In the schematics (sheet 1/7, ”AT91SAM7SE-EK Diagram”), the MCLK and BCLK sources implementation does not guarantee a correct phase relation as specified in the clocking AT73C213 datasheet.
  • Page 33 Errata AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...

  • Page 34: Revision History

    Revision History Revision History Table 7-1. Change Document Comments Request Ref. 6241A First issue. Section 6.2 ”TWI line pullups for Fast 6241B Added errata 4085 Mode operation” Section 6.3 ”AT73C213 clocking” Added errata 4226 AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...
  • Page 35 Revision History AT91SAM7SE-EK Evaluation Board User Guide 6241B–ATARM–22-Mar-07...
  • Page 36 Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDI- TIONS OF SALE LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY...
