6.9

SD/MMC- MCI1

Connector J5 is the SD/MMC connector.
Figure 6-9.
Table 6-9. SD/MMC1 Connector J5 Signal Descriptions
Pin
1
3
5
7
9
11
13
6.10

AC97

Connector J7 is the Headphone connector.
Connector J8 is the Line In connector.
Connector J9 is the Line In connector.
Connector JP15 is the Speaker Output connector
Figure 6-10. Audio Connector J7, J8, J9
Table 6-10. J7, J8, J9 Signal Description
Pin
Central pin
AT91SAM9G45-EKES User Guide
SD/MMC1 Connector J5
Mnemonic Pin
RSV/DAT3 2
GND 4
CLK 6
DAT0 8
DAT2 10
DAT4 12
DAT6 14
Mnemonic
Signal
Mnemonic
CMD
VCC
DAT1
DAT3
DAT5
DAT7
Connectors
6-7
6481B–ATARM–27-Nov-09
