Configuration
5.5.4

Multiplexing on PIO Controller C (PIOC)

Table 5-6. PIO Multiplexing Port C
I/O Peripheral A
PC0 DQM2
PC1 DQM3
PC2 A19
PC3 A20
PC4 A21/NANDALE
PC5 A22/NANDCLE
PC6 A23
PC7 A24
PC8 CFCE1
PC9 CFCE2
PC10 NCS4/CFCS0
PC11 NCS5/CFCS1
PC12 A25/CFRNW
PC13 NCS2
PC14 NCS3/NANDCS
PC15 NWAIT
PC16 D16
PC17 D17
PC18 D18
PC19 D19
PC20 D20
PC21 D21
PC22 D22
PC23 D23
PC24 D24
PC25 D25
PC26 D26
PC27 D27
PC28 D28
PC29 D29
PC30 D30
PC31 D31
5-6
6481B–ATARM–27-Nov-09
Peripheral B
RTS2
TCLK2
CTS2
Function and Comments
Add19 Flash AT49SV322
Add20 Flash AT49SV322
ALE Flash AT49SV322
CLE Flash AT49SV322
Ready/Busy NAND Flash
Chip select NAND Flash
Power
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
VDDIOM1
