6.4

Ethernet

Connector J15 is the RJ-45 Ethernet Connector.
Figure 6-4.
Table 6-4. Ethernet RJ45 Connector J15 Signal Descriptions
Pin
1
3
5
7
6.5

USB Host

Connector J12 is the USB Host connector.
Figure 6-5.
Table 6-5. USB Host Type A Connector J12 Signal Descriptions
Pin
1
2
3
4
5
AT91SAM9G45-EKES User Guide
Ethernet RJ45 Connector J15
Mnemonic
TxData+ DIFFERENTIAL OUTPUT PLUS
RxData+ DIFFERENTIAL INPUT PLUS
Shield
Shield
USB Host type A connector J12
Mnemonic Signal description
Vbus 5v power
DM Data minus
DP Data plus
Gnd Ground
Shield Shield
Pin Mnemonic
2 Txdata- DIFFERENTIAL OUTPUT MINUS
4 Shield
6 RxData- DIFFERENTIAL INPUT MINUS
8 Shield
Connectors
6-3
