System Accuracy 1
no signal attenuation
up to 95% signal attenuation
up to 95% signal attenuation
Repeatability
Temperature Resolution
Response Time
Temperature Coefficient
Emissivity (1‐color)
Slope (2‐color)
Max. Signal Reduction
Signal Processing
3.2 General Specifications
Display
Environmental Rating
Ambient Temperature
Head / Fiber Cable
Electronics Housing
Storage Temperature
Electronics Housing
Fiber Cable
Relative Humidity
Electromagnetic Interference
Mechanical Shock
Electronics Housing
Vibrations
Electronics Housing
at ambient temperature 23°C ±5°C (73°F ±9°F)
1
Marathon Series FA/FR
±(0.3% T + 2°C)
meas *
±(1% T + 2°C) for FR1A/FR1B
meas *
±(1.3% T + 2°C) for FR1C
meas *
*
T in °C
meas
see also appendix 11.4 and 11.5, pages 57 ff.
±1°C (±2°F)
±1°C (±2°F)
10 msec (95%), selectable to 10 sec
±0.1% of reading at ambient temperature from 0 to 60°C
0.10 to 1.00, in 0.01 increments
0.850 to 1.150 in 0.001 increments
95% at 600°C (1112°F), 50% at 500°C (932°F) for FR1A
95% at 875°C (1607°F), 50% at 700°C (1292°F) for FR1B
95% at 1300°C (2372°F), 50% at 1000°C (1832°F) for FR1C
Peak Hold, averaging, hold time 0 – 299.9 sec, in 0.1 sec
increments, 300.0 sec holds with external trigger
7‐segment LED display, individual LED's indicate modes
NEMA‐4 (IEC 529, IP 65) rated with conduit adapter and
compression fitting (which prevents liquid from entering
through the connector)
0 to 200°C (32°F to 360°F)
0 to 60°C (32°F to 140°F), with cooling platform: 150°C (300°F)
‐20 to 70°C (‐4°F to 158°F)
rated to 200°C (360°F), stainless steel armour, Viton coated,
NEMA‐4 (IP65)
for a high temperature fiber cable, see section 7 Options, on
page 33.
10 to 95%, not condensing at 22°C to 43°C (72°F to 110°F)
IEC 61326‐1
MIL‐STD‐810D (IEC 68‐2‐27), 50 G, 11 msec duration, any axis
MIL‐STD‐810D (IEC 68‐2‐6), 3 G, 11 to 200 Hz any axis
Technical Data
