3.5.2.2 Close Focus
Distance D to Object [mm]
D:S = 20:1 at focus point
Distance D to Object [mm]
D:S = 40:1 at focus point
Distance D to Object [mm]
D:S = 65:1 at focus point
3.6 Scope of Delivery
The scope of delivery includes the following:
Marathon FA/FR Documentation and Support CD
Mounting nuts
Adjustable mounting bracket (XXXFOMB)
12
[inch]
FR1A CF1
[inch]
FR1B CF1
[inch]
FR1C CF1
Figure 9: Close Focus Spot Size Charts for FR models
Distance D to Object [mm]
D:S = 20:1 at focus point
Distance D to Object [mm]
D:S = 40:1 at focus point
Distance D to Object [mm]
D:S = 65:1 at focus point
Marathon Series FA/FR
[inch]
FR1A CF2
[inch]
FR1B CF2
[inch]
FR1C CF2
