Operation
The sensor has a remote locking feature that keeps the unit from being accidentally changed from the
control panel (locked by default in multidrop mode). This lockout mode denies access to all the
switches on the control panel. It is available through the RS485 connection and can be unlocked only
by a command from the remote computer.
6.2 Operation Modes
When you first turn the unit on, the display shows the current temperature. Pushing the mode selector
button will change the figures on the display to the current setting for each particular mode. The
following figure illustrates the sequence of operation for the mode selector button when in current
temperature mode.
Display current temperature
Display/Change emissivity
default: 1.00
Display/Change peak hold setting
default = 0 sec / off
Display/Change averaging setting
default = 0 sec / off
Display/Change valley hold setting
default = 0 sec / off
26
Figure 24: Mode Selector Button Sequence (FA Models)
Switches between °C and °F
Raises and lowers emissivity
Raises and lowers
peak hold timing
Raises and lowers
averaging time
Raises and lowers
valley hold timing
