It is possible to activate a known preset or sequence from a connected fixture
when DMX is not present. If a connected fixture activates a preset or sequence
that is not recognized by the Spot fixture, the Spot fixture will hold its last look.
When DMX is restored, the DMX takes priority.

Pre-configured presets

Preset
1
2
3
4
5
6

Pre-configured sequences

Sequence
1
2
3
4
5

Adjusting the intensity of presets

Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
The fixture will automatically return to the Preset/Sequence menu after
5 seconds of inactivity without saving edits to the preset intensity. This cancels
unsaved changes.
ColorSource Spot
Name
3200K White
5600K White
Red
Green
Blue
Cyan
Name
Rainbow Fast
Rainbow Slow
Warm Colors Fast
Cool Colors Fast
Random
Ensure that DMX data is not present.
Press the Mode button to access the Preset/Sequence menu,
and then press the Up and Down buttons to select the preset
that you want to edit.
Hold the Mode button for 3 seconds. The display shows
where the number is an intensity level from
Press the Up and Down buttons to change the intensity level
of the preset in real time.
Press the Mode button to confirm your selection and return to
the Preset/Sequence menu.
Page 6 of 12
ColorSource Spot
Preset Name
7 Magenta
8 Yellow
9 Orange
10 Light Yellow
11 Light Blue
12 Light Pink
Electronic Theatre Controls, Inc.

: ##
  
, or .
