Adjusting the tilt

The fixture can be tilted up and down and rotated (panned) as needed.
Step 1:
Step 2:
Step 3:

User interface

The user interface allows you to set the start address of the fixture, and access
the stand-alone presets and sequences. After five seconds of inactivity, the
display goes dark.

Mode button

Pressing the Mode button activates the Preset/Sequence selection menu; the
last active preset or sequence plays automatically. Pressing the Mode button a
second time deactivates the selected preset or sequence. The display will revert
to show the DMX start address.
• If DMX data is present, the current preset or sequence plays in the
background and DMX data continues to take priority.
• If DMX data is lost and a preset is active in the background, the last
selected preset or sequence automatically plays.

Setting the DMX address

Step 1:
Step 2:
ColorSource Spot
Loosen, but do not remove the yoke locking knobs.
Tilt the fixture to the desired angle.
Tighten the yoke locking knobs.
Press the Mode button until the DMX address is displayed.
Use the Up and Down buttons to select the DMX address for
the fixture.
