D General
• Frequency coverage (MHz): TX
RX
WX 161.650 to 163.275*
1
* : IC-A24 only, IC-A6; 118.000 to 136.975 MHz
* 2 : U.S.A. version only.
• Mode : 6K00A3E
16K0G3E
• Channel spacing : 25 kHz
• Number of memory channels : 200 (20 CH. × 10 BANK)
• Power supply requirement : Specified battery packs/case or
11.0 V DC at external DC jack
• Usable temp. range : –10˚C to +60˚C (+14°F to +140°F)
• Current drain :
Tx 1.5 A typical
Rx 70 mA typical (at stand by)
300 mA typical.(at AF max.)
: BNC 50 Ω (nominal)
• Antenna connector
• Dimensions : 54(W)×129.3(H)×35.5(D) mm
(projections not incl.) 2
• Weight : Approx. 180 g (6.35 oz)
(Without the battery pack and antenna.)
All stated specifications are subject to change without
notice or obligation.
Page 31
D Transmitter
• Output power
118.000 to 136.975
1
108.000 to 136.975*
• Modulation
2
• Modulation limiting
• Audio harmonic distortion : Less than 10% (at60 % mod.)
• Hum and noise ratio
• Spurious emissions
(161.65 to 163.275 MHz)
• Microphone connector
D Receiver
• Receive system
• Intermediate frequencies
•Sensitivity VOR (AM 6dB S/N): Less than –3 dBµ typical
• Squelch sensitivity
(W) × 5 (H) × 1
1 3 13 (D) inch
⁄ ⁄ ⁄
8 32 32
• Selectivity
• Spurious response
rejection
• Audio output power
• Noise and hum
• External SP connector

SPECIFICATIONS

: 5 W (PEP) typical
1.5 W (CW) typical
: Low level modulation
: 70 to 100%
: More than 35 dB
: More than 46 dB (except oper-
ating frequency ±6.25 Hz range)
: 3-conductor 2.5(d) mm (
more than 100 kΩ
: Double conversion
superheterodyne
: 1st 30.05 MHz
2nd 450 kHz
COM (AM 6dB S/N): Less than –6 dBµ typical
WX (FM 12dB SINAD): Less than –13 dBµ typical
: AM Less than 0 dBµ
FM Less than –7 dBµ
: More than 7.5 kHz/–6 dB)
Less than 25 kHz/–60 dB)
: AM More than 60 dB
FM More than 30 dB
: More than 500 mW typical
(at 10% distortion with an 8 Ω
load, 30% mod.)
: More than 40 dB at 30% mod.
: 3-conductor 3.5 (d) mm
˝)/8 Ω
