ACCESSORY ATTACHMENT
D Antenna
CAUTION:
DO NOT
transmit without an antenna. Other-
wise the transceiver may be damaged.
Insert the supplied antenna into the antenna connector and
screw down the antenna as shown below.
7
Page 8
D Belt clip
Conveniently attaches to your belt.
Attach the belt clip with the supplied screws as below.
D Battery pack replacement
Before replacing the battery pack, push [PWR] for 2 sec. to
turn the power OFF.
Slide the battery release button forward, then pull the battery
pack upward with the transceiver facing away from you.
NOTE: Use the supplied screws only.
Supplied screws
