OPTIONS

D BATTERY CASE AND PACKS
• BP-208N
BATTERY CASE
Battery case for 6 × AA (R6) Alkaline cells.
• BP-209N
Ni-Cd BATTERY PACK
7.2 V/1100 mAh Ni-Cd battery pack.
• BP-210N
Ni-MH BATTERY PACK
7.2 V/1650 mAh Ni-MH battery pack.
• BP-211N
Li-Ion BATTERY PACK
7.4 V/1800 mAh Li-Ion battery pack.
D CHARGERS
• BC-110AR/DR
WALL CHARGER
The same as supplied with the transceiver.
•BC-119N + AD-101
DESKTOP CHARGER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is supplied with
the charger depending on versions. Charging time: approx. 1.5 to 2
hours.
•BC-121N - + AD-101
MULTI CHARGER
+ BC-124
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-101's are re-
quired) simultaneously. An AC adapter should be purchased sepa-
rately. Charging time: approx. 1.5 to 2 hours.
•BC-144N
DESKTOP CHARGER
For rapid charging of BP-209N (Ni-Cd) and BP-210N (Ni-MH).
31
Page 32
D BELT CLIPS
• MB-103
The same as supplied with the transceiver.
• MB-86
Belt clip for swivel type.
• MB-96F/96N
➥MB-96F: Attaches with the supplied belt clip (Fixed type).
➥MB-96N: Belt hanger for swivel type.
D DC CABLES
• CP-17L
Allows to charge the battery pack through a 12 V cigarette lighter
socket. (For BC-119N)
• OPC-254L
CHARGER ADAPTER
For operation and charging via an external power supply.
• OPC-656
Allows to charge the battery pack using 13.8 V power source in-
stead of the AC adapter for BC-121N.
(6 pcs.)
CHARGER ADAPTER
D OTHER OPTIONS
• OPC-499
When using an optional headset, such as those from the David
Clark Co. via the adapter, the transceiver outputs your transmitted
voice to the headset for monitoring.
• LC-159
Helps protect the transceiver from scratches, etc.
Usable options are depended on versions. Ask your dealer
or distributor for details.
BELT CLIP
SWIVEL BELT CLIP
LEATHER BELT HANGER
CIGARETTE LIGHTER CABLE
DC POWER CABLE
BC-121N
DC POWER CABLE FOR WITH DC
HEADSET ADAPTER CABLE
CARRYING CASE
