Det-Tronics X5200 Instructions Manual page 12

FIRE ALARM PANEL
ALARM
+
24 VDC
–
B2136
FIRE ALARM PANEL
ALARM
EOL
DEVICE 4
ALARM
+
24 VDC
–
B2137
8.2
o i TEST 3
WIRING NOTES:
1 IN NORMAL OPERATION WITH NO FAULTS OCCURRING, THE FAULT RELAY COIL IS ENERGIZED AND
THE NORMALLY OPEN (N.O.) AND COMMON (COM) CONTACTS ARE CLOSED.
2 ALARM RELAY IS NORMALLY DE-ENERGIZED WITH NO ALARM CONDITION PRESENT.
3 INDIVIDUAL MANUAL o i TEST SWITCHES CAN BE INSTALLED REMOTELY OR A DETECTOR SELECTOR AND
ACTIVATION SWITCH CAN BE INSTALLED AT THE FIRE PANEL. TEST SWITCHES ARE NOT SUPPLIED.
4 REFER TO SPECIFICATIONS SECTION FOR EOL RESISTOR VALUES. REFER TO EOL RESISTORS SECTION
FOR INSTALLATION DETAILS.
Figure 7—Ex d Wiring Option
o i TEST 3
WIRING NOTES:
1 IN NORMAL OPERATION WITH NO FAULTS OCCURRING, THE FAULT RELAY COIL IS ENERGIZED AND
THE NORMALLY OPEN (N.O.) AND COMMON (COM) CONTACTS ARE CLOSED.
2 ALARM RELAY IS NORMALLY DE-ENERGIZED WITH NO ALARM CONDITION PRESENT.
3 INDIVIDUAL MANUAL o i TEST SWITCHES CAN BE INSTALLED REMOTELY OR A DETECTOR SELECTOR AND
ACTIVATION SWITCH CAN BE INSTALLED AT THE FIRE PANEL. TEST SWITCHES ARE NOT SUPPLIED.
4 EOL RESISTOR SUPPLIED BY PANEL.
Figure 8—Ex e Wiring Option
X5200 DETECTOR
4-20 mA +
9 19
4-20 mA + REF
8 18
COM FIRE 2
7 17
COM FIRE
N.O. FIRE 2
6 16
N.O. FIRE
N.C. FIRE 2
5 15
N.C. FIRE
COM FAULT 1
4 14
COM FAULT
N.O. FAULT 1
3 13
N.O. FAULT
24 VDC +
2 12
1 24 VDC – 11
X5200 DETECTOR
9 4-20 mA + 19
4-20 mA + REF
8 18
COM FIRE 2
COM FIRE
7 17
N.O. FIRE 2
6 N.O. FIRE 16
N.C. FIRE 2
5 N.C. FIRE 15
COM FAULT 1
4 14
COM FAULT
N.O. FAULT 1
3 13
24 VDC +
2 12
1 24 VDC – 11
10
4-20 mA – SPARE
29
4-20 mA – REF SPARE
28
COM AUX 27
26
N.O. AUX
E.O.L.
DEVICE 4
N.C. AUX 25
RS-485 A 24
RS-485 B 23
MAN O i
24 VDC + 22
24 VDC – 21
24 VDC –
4-20 mA – SPARE 29
4-20 mA – REF
SPARE 28
COM AUX
27
N.O. AUX 26
N.C. AUX 25
RS-485 A 24
N.O. FAULT
RS-485 B 23
24 VDC + MAN O i
22
24 VDC – 24 VDC – 21
95-8546
