- Page 1 TAS3108EVM2 User's Guide Evaluation Module for the TAS3108 Digital Audio Signal Processor User's Guide NOVEMBER 2006 Digital Audio and Video Products SLEU065A...
- Page 2 TAS3108EVM2 User's Guide Evaluation Module for the TAS3108 Digital Audio Signal Processor User's Guide Literature Number: SLEU065A SEPTEMBER 2005 – Revised NOVEMBER 2006...
-
Page 3: Table Of Contents
Contents ..........................Preface ........................Overview ................TAS3108EVM2 System Features ....................... PCB Key Map ......................Input Board ....................... Output Board ....................Quick Setup Guide ................Electrostatic Discharge Warning ....................Unpacking the EVM ....................Power Supply Setup ..................Digital Audio Inputs/Outputs .................... - Page 4 List of Figures ..................... TAS3108EVM2 System ............Physical Structure for the TAS3108EVM2 (Rough Outline) ......................Input Board Outline ............. Physical Structure for Output DAC8-DIT2 Board Outline ......................Complete System ....................TAS3108 GDE Window ....................J200… J203 Pin Pumbers ......................J140 Pin Numbers ....................
-
Page 5: Preface
SLEU065A – SEPTEMBER 2005 – Revised NOVEMBER 2006 Read This First About This Manual This manual describes the operation of the TAS3108EVM2 evaluation module from Texas Instruments. How to Use this Manual This document contains the following chapters: Chapter 1 - Overview... -
Page 6: Related Documentation From Texas Instruments
Related Documentation from Texas Instruments The following table contains a list of data manuals that have detailed descriptions of the integrated circuits used in the design of the TAS3108EVM2. The data manuals can be obtained at the URL http://www.ti.com. Table 1. Related Documentation from Texas Instruments... -
Page 7: Overview
Chapter 1 SLEU065A – SEPTEMBER 2005 – Revised NOVEMBER 2006 Overview The TAS3108EVM2 PurePath Digital™ customer evaluation amplifier module demonstrates the digital audio processor TAS3108/TAS3108IA from Texas Instruments (TI). TAS3108DCP/TAS3108IADCP is a fully programmable high-performance audio processor. It uses an efficient, custom, multi-instruction programming environment... -
Page 8: Tas3108Evm2 System Features
TAS3108 EEPROM Optical and Optical and Coaxial Coaxial I2S Bus I2S Bus S/PDIF Ouput S/PDIF Input Example Example TI Input-USB Board TI DAC-DIT Board Figure 1-1. TAS3108EVM2 System Overview SLEU065A – SEPTEMBER 2005 – Revised NOVEMBER 2006 Submit Documentation Feedback... -
Page 9: Pcb Key Map
Figure 1-2. Figure 1-2. Physical Structure for the TAS3108EVM2 (Rough Outline) U41 is the TAS3108 device. U33 is the EEPROM for program and coefficient storage. Digital audio data (I2S) is input on J12 and output on J22. J11 is used for I2C control, reset signal, and power-supply voltage. -
Page 10: Input Board
www.ti.com Input Board Input Board The input board contains an eight-channel ADC, SPDIF receiver, and USB connection. Buttons for MUTE, RESET, and selection between 48-kHz and 96-kHz sample rate. Physical structure for the input-USB board is illustrated in Figure 1-3. USB Connector USB Connect or RESET Button (Board) -
Page 11: Output Board
www.ti.com Output Board Output Board • Eight-channel digital-to-analog converter, two PCM4104 devices, automatic sample-rate detection, and supports 44.1 kHz, 48 kHz, and 96 kHz in this application. Relation between master clock and sample rate clock must be 256. 4-Vrms for 0-dB and 116-dB DYR A-weighted. •... -
Page 12: Complete System
Output Board A picture of the complete system is shown in Figure 1-5. The input board is to the left, the TAS3108EVM2 is in the middle, and the output board is to the right. Figure 1-5. Complete System Overview SLEU065A –... -
Page 13: Quick Setup Guide
SLEU065A – SEPTEMBER 2005 – Revised NOVEMBER 2006 Quick Setup Guide This chapter describes the TAS3108EVM2 board, with regard to power supplies and system interfaces. The chapter provides information regarding handling and unpacking, absolute operating conditions, and a description of the factory default switch and jumper configuration. -
Page 14: Electrostatic Discharge Warning
Electrostatic Discharge Warning Electrostatic Discharge Warning Many of the components on the TAS3108EVM2 are susceptible to damage by electrostatic discharge (ESD). Customers are advised to observe proper ESD handling precautions when unpacking and handling the EVM, including the use of a grounded wrist strap at an approved ESD workstation. -
Page 15: Power Supply Setup
Power Supply Setup Power Supply Setup The TAS3108EVM2 is powered via the DAC8-DIT2 board or another output board, like a TAS5086-5186EVM. The DAC8-DIT2 board generates a +5-V supply that is fed to the TAS3108EVM2. The +5-V supply is further regulated to +3.3 V with the aid of a low-dropout linear regulator, U31. -
Page 16: Tas3108 Software Installation
3. Start GDE program from the Windows Start menu. Startup of GDE requires a few seconds. Figure 2-1. TAS3108 GDE Window To test the connection from PC to EVM, load the TAS3108EVM2 test file (helloworld.pfw), located in C:\Program Files\Texas Instruments Inc\TAS3108 Development Tools\Examples\HelloWorld.pfw. -
Page 17: System Interfaces
Chapter 3 SLEU065A – SEPTEMBER 2005 – Revised NOVEMBER 2006 System Interfaces This chapter describes the TAS3108EVM2 board regard to power supplies and system interfaces....................Topic Page ............Control Interface (J11), Input ..........Digital Audio Interface, Input (J12) ............ -
Page 18: Control Interface (J11), Input
Control Interface (J11), Input Control Interface (J11), Input This interface connects the TAS3108EVM2 board to a TI input-USB board. This is a general-purpose interface, so not all signals are used by the TAS3108. Unused signals are shaded in Table 3-1. -
Page 19: Digital Audio Interface, Input (J12)
www.ti.com Digital Audio Interface, Input (J12) Digital Audio Interface, Input (J12) The digital audio interface contains digital audio signal data (I2S), clocks, etc. See the TAS3108 data manual for signal timing and details not covered in this document. Table 3-2. J12 Pin Description NET-NAME AT DESCRIPTION NUMBER... -
Page 20: Control Interface, Output (J21)
Control Interface, Output (J21) Control Interface, Output (J21) This interface connects the TAS3108EVM2 board to a TI DAC8-DIT2 output board or a general amplifier power EVM. This is a general-purpose interface, so not all signals are used by the TAS3108. Unused... -
Page 21: Digital Audio Interface, Output (J22)
www.ti.com Digital Audio Interface, output (J22) Digital Audio Interface, output (J22) The digital audio interface contains digital audio signal data (I2S), clocks, etc. See the TAS3108 data manual for signal timing and details not covered in this document. Table 3-4. J22 Pin Description PIN NO. -
Page 22: 3.5.2 Spdif Coax
www.ti.com Connectors on the Input-USB board 3.5.2 SPDIF Coax The SPDIF input for coax is shown in Figure 3-2. PCB Connector (Top View) Figure 3-2. J140 Pin Numbers Table 3-6. J140 Pin Description PIN NO. NET-NAME AT DESCRIPTION SCHEMATICS Ground Coax SPDIF input Coax SPDIF input Coax SPDIF input... -
Page 23: Ap Psia Settings Using External I2S Source
www.ti.com Connectors on the Input-USB board Figure 3-4. AP PSIA Settings Using External I2S Source Figure 3-5. AP PSIA Interface Pin Numbers Table 3-7. AP PSIA Pin Description NET-NAME AT DESCRIPTION PIN NO. SCHEMATICS MCLK MCLK Source From MCLK source MCLK Out MCLK output Ground... -
Page 24: I2C Connector (J301)
www.ti.com Connectors on the Input-USB board Table 3-7. AP PSIA Pin Description (continued) NET-NAME AT DESCRIPTION PIN NO. SCHEMATICS SDATA4 SDATA4 Source From SPDIF or analog channels 7 and 8 SDATA4 Out SDATA4 output SDATA1 Out Connected to SDATA1 Out 3.5.4 I2C Connector (J301) PCB Connector (Top View) Figure 3-6. -
Page 25: Connectors On The Dac8-Dit2 Board
www.ti.com Connectors on the DAC8-DIT2 Board Table 3-9. J800 Pin Description (continued) PIN NO. NET-NAME AT DESCRIPTION SCHEMATICS GPIO6 General-purpose port for GUIs Shutdown reporting Shutdown reporting Temperature warning Temperature warning RESERVED Ground Ground RESERVED RESERVED RESERVED RESERVED Ground Ground +5-Vdc power supply (output) +5-Vdc power supply (output) Connectors on the DAC8-DIT2 Board... -
Page 26: 3.6.2 3.6.2 Spdif Coax
www.ti.com Connectors on the DAC8-DIT2 Board 3.6.2 3.6.2 SPDIF Coax The SPDIF input for coax is shown in Figure 3-8. PCB Connector (Top View) Figure 3-8. J62 Pin Numbers Table 3-11. J62 Pin Description PIN NO. NET-NAME AT DESCRIPTION SCHEMATICS Ground Coax SPDIF output Coax SPDIF output... - Page 27 EVALUATION BOARD/KIT IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including product safety measures typically found in the end product incorporating the goods.
-
Page 28: Important Notice
TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated products in automotive applications, TI will not be responsible for any failure to meet such requirements. Following are URLs where you can obtain information on other Texas Instruments products and application solutions: Products... - Page 29 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments TAS3108EVM2...
