Digital Audio Interface, Input (J12)

The digital audio interface contains digital audio signal data (I2S), clocks, etc. See the TAS3108 data
manual for signal timing and details not covered in this document.
PIN NET-NAME AT
NUMBER SCHEMATICS
1 GND
2 MCLK
3 GND
4 SDIN1
5 SDIN2
6 SDIN3
7 SDIN4
8
9
10 GND
11 SCLK
12 GND
13 LRCLK
14 GND
15
16 GND
SLEU065A – SEPTEMBER 2005 – Revised NOVEMBER 2006
Submit Documentation Feedback
Table 3-2. J12 Pin Description
Ground
Master clock input
Ground
I2S data 1, Channel 1 and 2
I2S data 2, Channel 3 and 4
I2S data 3, Channel 5 and 6
I2S data 4, Channel 7 and 8
Reserved
Reserved
Ground
I2S bit clock
Ground
I2S left-right clock
Ground
Reserved
Ground

Digital Audio Interface, Input (J12)

DESCRIPTION
System Interfaces 19
