Connectors on the Input-USB board
PIN NO.
SDATA4
1
SDATA4 Source
2
SDATA4 Out
3
SDATA1 Out

3.5.4 I2C Connector (J301)

PIN NO.
NET-NAME AT
SCHEMATICS
1
SCL
2
SDA
3
GND

3.5.5 Control Interface (J800)

This interface connects the EVM.
PIN NO.
NET-NAME AT
SCHEMATICS
1
GND
2
RESERVED
3
GND
4
RESET
5
RESERVED
6
MUTE
7
RESERVED
8
RESERVED
9
RESERVED
10
SDA
11
GND
12
SCL
13
GPIO1
14
GPIO2
15
GPIO3
16
GPIO4
17
GND
18
GPIO5
24
System Interfaces
Table 3-7. AP PSIA Pin Description (continued)
NET-NAME AT
SCHEMATICS
From SPDIF or analog channels 7 and 8
SDATA4 output
Connected to SDATA1 Out
PCB Connector (Top View)
Figure 3-6. J301 Pin Numbers
Table 3-8. J301 Pin Description
I2C clock
I2C data
Ground
Table 3-9. J800 Pin Description
Ground
Ground
System reset (bidirectional). Activate MUTE before RESET for quiet reset.
Activate MUTE pin on modulator
I2C data clock
Ground
I2C bit clock
General-purpose port for GUIs
General-purpose port for GUIs
General-purpose port for GUIs
General-purpose port for GUIs
Ground
General-purpose port for GUIs
DESCRIPTION
3
2
1
DESCRIPTION
DESCRIPTION
SLEU065A – SEPTEMBER 2005 – Revised NOVEMBER 2006
