- Page 1 TAS3208EVM Evaluation Module for TAS3208 Digital Audio Signal Processor User's Guide February 2008 Digital Audio & Video Products SLEU092...
- Page 2 TAS3208EVM Evaluation Module for TAS3208 Digital Audio Signal Processor User's Guide Literature Number: SLEU092 February 2008...
-
Page 3: Table Of Contents
Contents ..........................Preface ........................Overview .................. TAS3208EVM System Features ...................... PCB Key Map ....................Quick Setup Guide ................ Electrostatic Discharge (ESD) Warning ....................Unpacking the EVM ....................Power-Supply Setup ..................Digital Audio Inputs/Outputs ................... Master/Slave Mode Operation ....................2.5.1 Master Mode .................... - Page 4 Loading a Process Flow (Part B) ....................GDE Test Process Flow ....................Example MSP430 Control List of Tables ................ Related Documentation from Texas Instruments ..............DAC8DIT2 Board Recommended Supply Voltages ..................JP3 Clock Master/Slave Setting ....................Control1 Pin Description ......................
-
Page 5: Preface
The following table contains a list of data manuals that have detailed descriptions of the integrated circuits used in the design of the TAS3208EVM. The data manuals can be obtained at the URL http://www.ti.com. Table 1. Related Documentation from Texas... - Page 6 1. Graphical Development tool (GDE) for TAS3208 (GDE ver. TBD or later) 2. General Application Notes Trademarks Equibit™ and PurePath Digital™ are trademarks of Texas Instruments. All other trademarks are the property of their respective owners. Read This First SLEU092 – February 2008...
-
Page 7: Overview
Chapter 1 SLEU092 – February 2008 Overview The TAS3208EVM PurePath Digital™ customer evaluation amplifier module demonstrates the Digital Audio Processor TAS3208/TAS3208IA from Texas Instruments (TI). TAS3208DCP/TAS3208IADCP is a fully programmable high-performance audio processor. It uses an efficient, custom, multi-instruction programming environment optimized for digital audio processing algorithms. -
Page 8: Tas3208Evm System Features
TAS3208EVM System Features TAS3208EVM System Features • Socketed EEPROM for download of program and coefficients • 8-channel discrete I S input/outputs • 2-channel SPDIF receiver, optical input, into TAS3208 SDIN1 • 2-channel SPDIF transmitter, optical output from TAS3208 SDOUT1 •... -
Page 9: Tas3208Evm System
USB In TUSB USB DAC Line 3.3V Control Analog Out 1 GPIO1 Analog Comp GPIO2 /RESET Output /MUTE GPIO3 GPIO4 DAC Line Control Analog Out 2 Input Input Figure 1-1. TAS3208EVM System SLEU092 – February 2008 Overview Submit Documentation Feedback... -
Page 10: Tas3208Evm System
EEPROM2 DACOUT2 LINEOUT 2 CONTROLLER SHT 6 SHT 9 SHT 4 MUTE EEPROM1 RESET-USB RESET2 TYPE A JACK SHT 7 SPDIF IN SPDIF OUT HEADPHONE (OPTICAL SHEET 8 Figure 1-2. TAS3208EVM System Overview SLEU092 – February 2008 Submit Documentation Feedback... -
Page 11: Pcb Key Map
PCB Key Map PCB Key Map The physical structure for the TAS3208EVM is shown in Figure 1-3. SPDIF I2S IN SPDIF SPDIF SPDIF I2S IN SDOUT2 I2S OUT + 9 V -9 V I2S Slave I2S Master Receiver Headphone... - Page 12 Overview SLEU092 – February 2008 Submit Documentation Feedback...
-
Page 13: Quick Setup Guide
SLEU092 – February 2008 Quick Setup Guide This chapter describes the TAS3208EVM board in regards to power supplies and system interfaces. The chapter provides information regarding handling and unpacking, absolute operating conditions, and a description of the factory default switch and jumper configuration. -
Page 14: Electrostatic Discharge (Esd) Warning
• TAS3208EVM board using one TAS3208DCP (1 pc.) • 9-V ac-to-dc adapters (2 pc.) • USB cable for connecting TAS3208EVM board to USB port on a PC for PurePath Studio™ software (1 pc.) • PurePath CD-ROM containing data sheets, application reports, user's guides, gerber files, and PC software tools (1 pc.) -
Page 15: Master/Slave Mode Operation
Reset button, or by receiving a reset signal through the USB interface. Following the receipt of reset, the TAS3208EVM loads the contents of EEPROM2 and comes up with Mute enabled, clock master mode enabled. -
Page 16: Gde Startup
After completing the software installation, turn on power supplies and connect the USB cable to the Input-USB board. To start the GDE, go to the Start menu and select All Programs/Texas Instruments/PurePath Studio/Pure Path Studio GDE. Figure 2-1. GDE Startup The start-up of GDE takes a few seconds. -
Page 17: Setting The I
www.ti.com TAS3208 Software Installation Figure 2-2. Setting the I C Initialization Sequence If the EVM is to be operate in Master mode, select 3208EVM_init_master.cfg. If the EVM is to be operate in Slave mode, select 3208EVM_init_slave.cfg. SLEU092 – February 2008 Quick Setup Guide Submit Documentation Feedback... -
Page 18: Specifying The I 2 C Initialization Sequence
www.ti.com TAS3208 Software Installation Figure 2-3. Specifying the I C Initialization Sequence Then verify that the “Execute on reset” box is checked. At this point, a process flow can be built using the TAS3208 application framework, the TAS3208 I/O components, and the audio processing components. Building and running a process flow A good starting point is to load the predefined TAS3208 Test process flow. -
Page 19: Loading A Process Flow
www.ti.com TAS3208 Software Installation Figure 2-4. Loading a Process Flow Select TAS3208TEST.pfw (see Figure 2-5). SLEU092 – February 2008 Quick Setup Guide Submit Documentation Feedback... -
Page 20: Loading A Process Flow (Part B)
www.ti.com TAS3208 Software Installation Figure 2-5. Loading a Process Flow (Part B) This will load a process flow that streams a signal from either the ADC or SAP1 input to the DAC and SAP outputs. Quick Setup Guide SLEU092 – February 2008 Submit Documentation Feedback... -
Page 21: Gde Test Process Flow
The TAS3208 then loads the EEPROM image and the TAS3208_init_master/slave.cfg file. At this point, the TAS3208EVM transitions to the run mode with the mute in the ON state. For the TAS3208 to stream audio out of the DAC outputs, the mute must be returned to the inactive state. - Page 22 Quick Setup Guide SLEU092 – February 2008 Submit Documentation Feedback...
-
Page 23: System Interfaces
Chapter 3 SLEU092 – February 2008 System Interfaces This chapter describes the TAS3208EVM board power supplies and system interfaces....................Topic Page ..........Control Interface (Control1), Input ..........Digital Audio Interface, Input (J1) ..............Analog Input (J6) ..........Digital Audio Interface, Output (J9) .............. -
Page 24: Control Interface (Control1), Input
Control Interface (Control1), Input Control Interface (Control1), Input This interface connects the TAS3208EVM board to an internal controller. This is a general-purpose interface. Table 3-1. Control1 Pin Description Pin No. Net-Name at Schematics Description C bidirectional data line C input clock line Ground 3.3 V... -
Page 25: Analog Input (J6)
www.ti.com Analog Input (J6) Analog Input (J6) Table 3-3. J6 Pin Description Pin No. Net-Name at Schematics Description Ground LineIn1L Line in left channel 1, also on RCA J5 Ground LineIn1R Line in right channel 1, also on RCA J5 Ground LineIn2L Line in left channel 2... -
Page 26: Rca Connectors
www.ti.com RCA Connectors Table 3-4. J9 Pin Description Pin No. Net-Name at Schematics Description Ground MCLKO Master clock output Ground SCLKout S bit clock Ground LRCLKout S left-right clock Ground SDOUT1 S data 1, channel 1 and 2 Ground SDOUT2 S data 2, channel 3 and 4 RCA Connectors Table 3-5. -
Page 27: Msp430 Port Connector (J3)
www.ti.com MSP430 Port Connector (J3) MSP430 Port Connector (J3) Table 3-6. J3 Pin Description Pin No. Net-Name at Schematics Description Test data out TCLK Test clock 3.3V 3.3 V power supply Test mode select Test clock TEST Test RESET Reset S Master Slave Jumper (JP3) PCB Connector (Top View) Table 3-7. - Page 28 System Interfaces SLEU092 – February 2008 Submit Documentation Feedback...
-
Page 29: Msp430 Programming
Chapter 4 SLEU092 – February 2008 MSP430 Programming This chapter describes the MSP430 programming....................Topic Page ..........Example of MSP430 Programming SLEU092 – February 2008 MSP430 Programming Submit Documentation Feedback... -
Page 30: Example Of Msp430 Programming
www.ti.com Example of MSP430 Programming Example of MSP430 Programming The MSP430 can be programmed to provide TAS3308 and power-stage initialization and control. During initialization, the MSP430 should wait for the TAS3308 to complete booting from EEPROM. It then sends an initialization sequence to the TAS3308. At this point, the MSP430 sends I C commands to the TAS3308 when it receives an input from one of the onboard switches or the IR remote control. -
Page 31: Important Notice
IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete. - Page 32 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments TAS3208EVM...
