PIN NO. NET-NAME AT
SCHEMATICS
19 GPIO6
20 SD1
21 SD2
22 TW1
23 TW2
24 RESERVED
25 GND
26 GND
27 RESERVED
28 RESERVED
29 RESERVED
30 RESERVED
31 GND
32 GND
33 +5V
34 +5V
3.6

Connectors on the DAC8-DIT2 Board

3.6.1 Analog Outputs

The mini-jack 3.5-mm connector for analog outputs is shown in
PIN NO. NET-NAME AT
SCHEMATICS
1 CH1
2 AGND
3
4 CH2
SLEU065A – SEPTEMBER 2005 – Revised NOVEMBER 2006
Submit Documentation Feedback
Table 3-9. J800 Pin Description (continued)
General-purpose port for GUIs
Shutdown reporting
Shutdown reporting
Temperature warning
Temperature warning
Ground
Ground
Ground
Ground
+5-Vdc power supply (output)
+5-Vdc power supply (output)
2 3
PCB Connector (Top View)
Figure 3-7. J71 to J74 Pin Numbers
Table 3-10. J71 Pin Description
Channel 1, left output – tip
Analog ground – sleeve
For future use
Channel 2, right output – ring

Connectors on the DAC8-DIT2 Board

DESCRIPTION
Figure 3-7.
1
4
DESCRIPTION
System Interfaces 25
