47
4.1.1

System Alarms Display Map

Display Points Alarm Point
17 Timed Tick
Network Time
19
Server
Accumulation
20
Event
11
Duplicate IP
21
Address
22 External
Sensor down
33 Unit Reset
36
Provisioning
Note: Table A.3 continues on following page.
Description
Toggles state at constant rate as
configured by the Timed Tick timer
variable. Useful in testing integrity of
SNMP trap alarm reporting.
Communication with Network Time
Server has failed.
An alarm has been standing for the
time configured under Accum. Timer.
The Accumulation timer enables you
to monitor how long an alarm has
been standing despite system reboots.
Only the user may reset the
accumulated time, a reboot will not.
The unit has detected another node
with the same IP Address.
External Sensor is not active
The unit has just come-online. The
set alarm condition is followed
immediately by a clear alarm
condition.
The internal NVRAM may be
Lost
damaged. The unit is using default
configuration settings.
Table A.3. System Alarms Descriptions
Solution
To turn the feature off, set the Timed
Tick timer to 0.
Try pinging the Network Time Server's
IP Address as it is configured. If the
ping test is successful, then check the
port setting and verify the port is not
being blocked on your network.
To turn off the feature, under
Accum.Timer, set the display and
point reference to 0.
Unplug the LAN cable and contact
your network administrator. Your
network and the unit will most likely
behave incorrectly. After assigning a
correct IP Address, reboot the unit to
clear the System alarm.
Check to see if external sensor cable
is properly connected.
Seeing this alarm is normal if the unit
is powering up.
Use Web or latest version of NGEdit4
to configure unit. Power cycle to see if
alarm goes away. May require RMA.
