4. Enter the IP address of the SNMP manager in the IPA field.
Note: SNMP trap format is v1.
2.5.4

TCP Paging Setup

Heading
MSG_BEG Sequential message number used to group the message and detect missing
MSG_END messages (e.g. 00001, 00002, etc...).
VID Vendor ID
FID NetGuardian Firmware ID.
SITE NetGuardian system name.
PNT Point ID (port.address.display.point). See Appendix A for display mapping.
DESC Description set forth in the Alarm parameters.
STAT Status of the alarm (Clear or Alarm).
DATE Date the alarm occurred.
TIME Time the alarm occurred.
The NetGuardian offers alarm status notification via multiple TCP ports. When an alarm condition occurs, an
alarm condition formatted according to Figure 2.5.4 will be sent to the specified TCP points for use by a higher
level master. This connection must be established by the master. Any applicable alarm activity occurring prior to
an established connection will be discarded.
Use the following steps to configure the TCP paging settings:
1. From the Edit menu> Notification screen, select an ID number to use (see Figure 2.5.1).
Note: Pager IDs are used in the alarm provisioning screen to designate the primary and secondary
person/device being paged when an alarm condition occurs or clears.
2. Under the Type column, select TCP from the drop-down menu (see Figure 2.5.1).
3. In the Pin/Rcpt/Port field, enter the NetGuardian TCP port number where alarm messages will be sent
(from 1 to 65,536). Multiple ports can be defined by defining multiple pager IDs as TCP pagers and then
entering the desired ports.
4. The TCP message can be viewed by a Telnet session by connecting to the NetGuardian's IP address and the
TCP port entered in this screen. For example, Telnet to 126.10.220.199 5000 if port 5000 is selected
and 126.10.220.199 is the unit's IP address. See Figure 2.5.4 for an example message and Table 2.5.4.A for
TCP message format information.
<MSG_BEG 00001>
VID : DPS Telecom
FID : NetGuardian SNMP v4.0B.0033
SITE: Yale Office
PNT : 99.01.01.01
DESC: RECTIFIER 1
STAT: CLEAR
DATE: 01/01/2001
TIME: 12:17:02
<MSG_END 00001>
Fig. 2.5.4. Example TCP message
Table 2.5.4.A. TCP alarm message field descriptions
Description
