Enter the interface of new project, as shown below, click "New Project", type the project
name, then will pop-up the interface of texture scan and resolution selection. Texture scan is only
active when the scanner is with texture camera. The process of Non-texture Scan and Texture
Scan are same.
Select Resolution
The higher the resolution, the better the details. If select the "More setting of Resolution",
you can drag the sliding block to other locations, flexible choice of point distance.
Handheld Rapid Scan point distance range: 0.7mm—3.0mm, high 0.7mm, medium 1.0mm,
low 1.5mm.
Note：
1.Higher resolution takes more time to scan and consumes more memory of
graphic card，and size of the object to be scanned will be limited. Theoretically, the
maximum size of scan = point distance*8192/mm. In actual process, the size of the
object can be scanned depending on computer graphic card.
2. Choose high resolution, the data output is slow, please be patient.
3. When import project, and continue the scan, the scanning will be in accordance
with the imported project resolution and align mode.
Select Texture
If texture camera is not attached, when you select texture,it will pop-up a dialog as shown below:
and p3.

Handheld Rapid Scan

, can import three formats as asc, txt
