Calibration - Shining 3D EinScan-Pro+ User Manual

Calibration

After software installed, in the choose device type interface choose "Pro+", click "Next", the
software will enter the calibration mode.
It will show the below picture if the device only has two cameras. (Texture camera is not
attached). The left side guide bar include camera calibration.
It will show the below picture if the device has three cameras. (With texture camera). The left
side guide bar include camera calibration and white balance calibration.
There are two calibration steps if the device without texture camera:
①camera calibration ;
There are two calibration steps if the device with texture camera:
①camera calibration White balance calibration.
Note:
Calibration board SN is under the camera viewport, you should choose the
corresponding calibration board.
Take the scanner with texture camera as an example (without texture camera, it only takes the
first steps).
