HDP 101 4K • User Guide (Continued)
•
Includes LockIt
HDMI cable lacing brackets.
®
Supports LPCM audio.
•
•
Highly reliable, energy-efficient external universal power supply included — Provides worldwide power compatibility,
with high demonstrated reliability and low power consumption for reduced operating costs.
Application Diagram
Figure 1.
HDP 101 4K Application
Mounting
Use the included hook-and-loop tape to attach the HDP 101 4K to the application surface.
Blu-ray Disc
Laptop
HDMI
Extron
HDP 101 4K
HDMI to DisplayPort
Converter
PC
HDMI
HDMI
R
W E
T
P O
S I G
O U
V
X
1 2
M A
D P
- - A
DisplayPort
4K Display
2
