Chapter 4

4.5 Replacing the Drive Roller

Over time, the platen may harden and cause print issues and need to be replaced. The
printer is equipped with an easy replaceable drive roller assembly.
1. Loosen and unscrew the 2 pressed in captive screw that holds the top cover in place
and rotate to the open position.
2. Release the Print Head Assembly and rotate to the open position.
485TC Operator's Manual - 880058-0100
Figure 4-5 Cleaning the Print Head
Figure 4-6 Releasing the Print Mechanism
Printer Maintenance
The printhead dot row
should be cleaned to
remove any
contaminates that may
impact print quality.
4-5
