Chapter 3

3.15 Wristband Media Adapter Option

When 1" wide wristband media is being used, the wristband option should be installed. The
wristband guide is inserted into the media guide and is locked into place.
Wristband Guide
485TC Operator's Manual - 880058-0100
Insert into media guide
making sure that it is
flush against the green
media guide

Figure 3-13 Wristband Media Adapter

Loosen locking nut and
slide guide into place
and retighten into place
Getting Started
3-13
