Chapter 10

10.5 Replacing the Drive Roller

Over time, the platen may harden and cause print issues and need to be replaced. The
printer is equipped with an easy replaceable drive roller assembly.
1. Slide the black latches towards the center to release the printhead assembly and
then rotate to the open position.
428TM Operator's Manual - 880042-0141

Figure 10-5 Cleaning the Print Head

Figure 10-6 Releasing the Print Mechanism

Printer Maintenance
The printhead dot row
should be cleaned to
remove any
contaminates that may
impact print quality.
10-5
