Chapter 1: Printer Specifications; General Specifications; Printing Specifications - Microcom 485TC Operator's Manual

Chapter 1:

1.1 General Specifications

Width*
Height*
Depth*
Weight*
Electrical
Current
Temperature
Humidity
RAM Memory
Flash Memory
Agency Approvals
Interface Communications
Flow Control
Baud Rate
Parity
Data Bits
* NOTE: Listed specifications are based on a standard print mechanism and may vary

1.2 Printing Specifications

Print Type
Print Resolution
Maximum Print Speed
Maximum Print Width
Maximum Print Length
Minimum Print Length
485TC Operator's Manual - 880058-0100
Printer Specifications
7.3" (185 mm)
7.4" (188 mm)
5.8" (148 mm)
10.2 lbs. (4.6 kg)
+24 VDC
3.5 Amps maximum
40° F – 104° F (5° C – 40° C), operating
10% – 85%, non-condensing
256 Mb
512 Mb
RoHS, FCC Class A, cTUVus
RS232, USB, and Ethernet Ports
CTS/RTS Hardware
Up to 115200
Odd, Even, and None
7 or 8
Table 1-1 General Specifications
based on final configuration.
Direct Thermal
203 DPI (8 dots/mm = 0.0049" per dot)
300 DPI (12 dots/mm = 0.0032" per dot)
Up to 10"/sec. (250 mm/sec.)
203 DPI = 4.098" (104.10mm); 832 dots
300 DPI = 4.252" (108 mm); 1,280 dots
26" (660 mm)
0.25" (6 mm)
Table 1-2 Printing Specifications
1-1
